PositionLayout 是什么

PositionLayout 是位置布局，在PositionLayout中，子组件通过指定准确的x/y坐标值在屏幕上显示。(0, 0)为左上角；当向下或向右移动时，坐标值变大；允许组件之间互相重叠。看到这个描述感觉实际开发中应该很少用到这个布局，本着学习的态度，简单的了解它的使用

PositionLayout  的属性

ohos:position_x  控制x 轴方向的位置

ohos:position_y 控制y轴方向的位置

x轴，y轴在屏幕的右上角，具体如下图

demo 练习PositionLayout 的使用

<?xml version="1.0" encoding="utf-8"?>
<PositionLayout
    xmlns:ohos="http://schemas.huawei.com/res/ohos"
    ohos:height="match_parent"
    ohos:width="match_parent"
    ohos:background_element="#3387CEFA">

    <Button
        ohos:id="$+id:button1"
        ohos:height="50vp"
        ohos:width="100vp"
        ohos:position_x="0vp"
        ohos:position_y="0vp"
        ohos:background_element="#00FFFF"
        ohos:text="Java"
        ohos:text_alignment="center"
        ohos:text_size="20fp"/>

    <Button
        ohos:id="$+id:button2"
        ohos:height="50vp"
        ohos:width="100vp"
        ohos:position_x="35vp"
        ohos:position_y="35vp"
        ohos:background_element="#FF0000"
        ohos:text="Java"
        ohos:text_alignment="center"
        ohos:text_size="20fp"/>


    <Button
        ohos:id="$+id:button3"
        ohos:height="50vp"
        ohos:width="100vp"
        ohos:position_x="75vp"
        ohos:position_y="75vp"
        ohos:background_element="#00d8a0"
        ohos:text="Java"
        ohos:text_alignment="center"
        ohos:text_size="20fp"/>

    <Button
        ohos:id="$+id:button5"
        ohos:height="50vp"
        ohos:width="100vp"
        ohos:position_x="125vp"
        ohos:position_y="115vp"
        ohos:background_element="#8B00FF"
        ohos:text="Java"
        ohos:text_alignment="center"
        ohos:text_size="20fp"/>

    <Button
        ohos:id="$+id:button6"
        ohos:height="50vp"
        ohos:width="300vp"
        ohos:position_x="175vp"
        ohos:position_y="175vp"
        ohos:background_element="#8B00FF"
        ohos:text="Java"
        ohos:text_alignment="center"
        ohos:text_size="20fp"/>



</PositionLayout>

实现的效果图如下

其他想法

本想着到这就了解忘了，不过突然间想到了既然它是通过x，y轴来控制 控件的位置，我们可以通过它来实现一个简答的移动，就是xml 一个位置，java 代码在写一个位置

xml 代码如下

<?xml version="1.0" encoding="utf-8"?>
<PositionLayout
    xmlns:ohos="http://schemas.huawei.com/res/ohos"
    ohos:height="match_parent"
    ohos:width="match_parent"
    ohos:background_element="#3387CEFA">

    <Button
        ohos:id="$+id:button1"
        ohos:height="50vp"
        ohos:width="100vp"
        ohos:position_x="0vp"
        ohos:position_y="0vp"
        ohos:background_element="#00FFFF"
        ohos:text="Java"
        ohos:text_alignment="center"
        ohos:text_size="20fp"/>

</PositionLayout>

java 代码

package com.example.myapplication.slice;

import com.example.myapplication.ResourceTable;
import ohos.aafwk.ability.AbilitySlice;
import ohos.aafwk.ability.OnClickListener;
import ohos.aafwk.content.Intent;
import ohos.agp.components.AttrHelper;
import ohos.agp.components.Button;
import ohos.agp.components.Component;

public class MainAbilitySlice extends AbilitySlice {
    private Button button1;
    @Override
    public void onStart(Intent intent) {
        super.onStart(intent);
        super.setUIContent(ResourceTable.Layout_ability_main);
        button1= (Button) findComponentById(ResourceTable.Id_button1);

        button1.setClickedListener(new Component.ClickedListener() {
            @Override
            public void onClick(Component component) {
                button1.setPosition(vp2px(200), vp2px(0));
            }
        });
    }

    private int vp2px(float vp){
        return AttrHelper.vp2px(vp,this);
    }


    @Override
    public void onActive() {
        super.onActive();
    }

    @Override
    public void onForeground(Intent intent) {
        super.onForeground(intent);
    }
}

xml 的位置

点击button 移动之后的位置

官方文档参考连接
