一、前言：当远程会议遇见空间交互

后疫情时代，远程协作已成为常态，但传统视频会议存在"互动感缺失"的痛点——参会者只能被动观看屏幕，无法像线下会议那样用手势指向重点、用表情传递态度。HarmonyOS 6（API 23）带来的 Face AR 与 Body AR 能力，让 PC 端设备可以化身为"空间协作终端"：演讲者抬手即可在白板上圈画重点，听众皱眉自动触发"疑问"标记，点头表示"赞同"实时统计，结合沉浸光感营造会议室氛围，让远程协作回归"面对面"的自然体验。

本文将实战开发一款 “AR 远程协作白板” 应用，面向 HarmonyOS PC 端。核心创新点在于：

• Face AR 表情反馈：实时捕捉点头（赞同）、摇头（反对）、皱眉（疑问）、挑眉（惊讶）等微表情，转化为会议情绪数据
• Body AR 手势标注：单手隔空指向白板坐标，双手捏合圈选区域，挥手翻页，实现"无接触式"演示
• 沉浸光感氛围：根据会议情绪热度（赞同/反对比例）动态调整 UI 光效——共识时绿光、争议时橙光、僵局时红光
• 悬浮导航控制：底部悬浮面板显示参会者情绪统计、手势模式切换，支持透明度调节，不遮挡白板内容

二、系统架构设计

2.1 空间协作架构

┌─────────────────────────────────────────────────────────────┐
│                    空间感知层（AR Engine 6.1.0）               │
│  ┌─────────────────────┐    ┌─────────────────────────────┐  │
│  │    Face AR 模块     │    │     Body AR 模块            │  │
│  │  · 68点人脸Mesh      │    │  · 20+骨骼关键点            │  │
│  │  · 64种BlendShape   │    │  · 6种手势状态识别           │  │
│  │  · 头部姿态追踪      │    │  · 3D空间位置追踪           │  │
│  └──────────┬──────────┘    └──────────────┬──────────────┘  │
└─────────────┼────────────────────────────────┼────────────────┘
              │                                │
              ▼                                ▼
┌─────────────────────────────────────────────────────────────┐
│                    语义映射引擎（ArkTS）                       │
│  ┌─────────────────────────────────────────────────────────┐ │
│  │  表情指令映射：                                          │ │
│  │    · 点头 (headPitch > 0.3)          →  agree()         │ │
│  │    · 摇头 (headYaw > 0.4)            →  disagree()      │ │
│  │    · 皱眉 (browDown > 0.5)           →  question()      │ │
│  │    · 挑眉 (browInnerUp > 0.6)        →  surprise()      │ │
│  │    · 微笑 (mouthSmile > 0.5)         →  like()          │ │
│  └─────────────────────────────────────────────────────────┘ │
│  ┌─────────────────────────────────────────────────────────┐ │
│  │  手势指令映射：                                          │ │
│  │    · 食指指向 (indexTip位置)           →  cursorMove()    │ │
│  │    · 双手捏合 (handDistance < 0.15)    →  selectArea()   │ │
│  │    · 单手挥动 (wristVelocity > 0.5)    →  flipPage()     │ │
│  │    · 双手张开 (handDistance > 0.4)     →  zoomIn()        │ │
│  │    · 握拳 (fingerCurl > 0.7)           →  drawMode()      │ │
│  └─────────────────────────────────────────────────────────┘ │
└─────────────────────────────────────────────────────────────┘
              │
              ▼
┌─────────────────────────────────────────────────────────────┐
│                    协作数据层（分布式软总线）                   │
│  · 情绪数据广播：本地表情 → 远端参会者情绪面板                  │
│  · 手势坐标同步：本地手势 → 远端白板标注叠加层                  │
│  · 白板状态同步：本地绘制 → 远端实时渲染                       │
└─────────────────────────────────────────────────────────────┘
              │
              ▼
┌─────────────────────────────────────────────────────────────┐
│                    沉浸交互层（ArkUI + HDS）                    │
│  ┌─────────────────────┐    ┌─────────────────────────────┐  │
│  │   情绪光感标题栏      │    │     悬浮协作面板            │  │
│  │  · 会议情绪热度色映射   │    │  · 参会者情绪统计           │  │
│  │  · 共识度光效指示       │    │  · 手势模式切换             │  │
│  │  · 发言者高亮光晕       │    │  · 白板工具栏               │  │
│  └─────────────────────┘    └─────────────────────────────┘  │
└─────────────────────────────────────────────────────────────┘

2.2 会议情绪光感映射

会议状态	情绪指标	光效颜色	标题栏氛围	触发条件
高度共识	赞同>80%	翠绿 #00D4AA	稳定呼吸光	全票通过
多数赞同	赞同>60%	青蓝 #4ECDC4	柔和脉冲	方案通过
存在争议	反对>30%	琥珀 #FFD700	渐强闪烁	意见分歧
严重分歧	反对>50%	赤红 #FF6B6B	急促警示	需要调解
疑问集中	疑问>40%	紫蓝 #9B59B6	呼吸渐变	需要解释
惊讶反馈	惊讶>20%	明黄 #FFE66D	脉冲爆发	亮点发现

三、环境配置与权限声明

3.1 模块依赖配置

{
  "dependencies": {
    "@hms.core.ar.arengine": "^6.1.0",
    "@kit.UIDesignKit": "^6.0.0",
    "@kit.DistributedServiceKit": "^6.0.0",
    "@kit.MultimediaKit": "^6.0.0",
    "@kit.Graphics2DKit": "^6.0.0"
  }
}

3.2 权限声明

{
  "module": {
    "requestPermissions": [
      { "name": "ohos.permission.CAMERA" },
      { "name": "ohos.permission.INTERNET" },
      { "name": "ohos.permission.DISTRIBUTED_DATASYNC" },
      { "name": "ohos.permission.DISTRIBUTED_SOFTBUS_CENTER" }
    ]
  }
}

四、核心代码实战

4.1 Face AR 情绪识别引擎（EmotionRecognitionEngine.ets）

代码亮点：将 Face AR 的 BlendShape 参数与头部姿态融合，识别 5 种会议情绪状态，并计算情绪置信度。

// entry/src/main/ets/engine/EmotionRecognitionEngine.ets
import { arEngine } from '@hms.core.ar.arengine';

export enum MeetingEmotion {
  AGREE = 'AGREE',           // 赞同
  DISAGREE = 'DISAGREE',     // 反对
  QUESTION = 'QUESTION',     // 疑问
  SURPRISE = 'SURPRISE',     // 惊讶
  LIKE = 'LIKE',             // 喜欢
  NEUTRAL = 'NEUTRAL'        // 中性
}

export interface EmotionResult {
  emotion: MeetingEmotion;
  confidence: number;        // 置信度 0-1
  intensity: number;         // 强度 0-1
  timestamp: number;
}

export class EmotionRecognitionEngine {
  private static instance: EmotionRecognitionEngine;

  // 表情阈值与权重配置
  private readonly EMOTION_CONFIG: Map<MeetingEmotion, {
    blendShapes: { [key: string]: number };
    headPose?: { pitch?: number; yaw?: number; roll?: number };
    weight: number;
    cooldown: number;
  }> = new Map([
    [MeetingEmotion.AGREE, {
      blendShapes: { mouthSmileLeft: 0.3, mouthSmileRight: 0.3 },
      headPose: { pitch: 0.25 },
      weight: 1.0,
      cooldown: 1500
    }],
    [MeetingEmotion.DISAGREE, {
      blendShapes: { mouthFrownLeft: 0.4, mouthFrownRight: 0.4 },
      headPose: { yaw: 0.35 },
      weight: 1.0,
      cooldown: 1500
    }],
    [MeetingEmotion.QUESTION, {
      blendShapes: { browDownLeft: 0.4, browDownRight: 0.4, mouthPucker: 0.3 },
      weight: 0.8,
      cooldown: 2000
    }],
    [MeetingEmotion.SURPRISE, {
      blendShapes: { browInnerUp: 0.6, eyeWideLeft: 0.5, eyeWideRight: 0.5 },
      weight: 0.9,
      cooldown: 2000
    }],
    [MeetingEmotion.LIKE, {
      blendShapes: { mouthSmileLeft: 0.5, mouthSmileRight: 0.5, cheekSquintLeft: 0.4 },
      weight: 0.7,
      cooldown: 1000
    }]
  ]);

  private lastEmotionTime: Map<MeetingEmotion, number> = new Map();
  private emotionHistory: EmotionResult[] = [];

  static getInstance(): EmotionRecognitionEngine {
    if (!EmotionRecognitionEngine.instance) {
      EmotionRecognitionEngine.instance = new EmotionRecognitionEngine();
    }
    return EmotionRecognitionEngine.instance;
  }

  /**
   * 识别当前面部情绪
   */
  recognizeEmotion(face: arEngine.ARFace): EmotionResult {
    const blendShapes = face.getBlendShapes();
    const headPose = face.getPose();
    const now = Date.now();

    if (!blendShapes) {
      return { emotion: MeetingEmotion.NEUTRAL, confidence: 0, intensity: 0, timestamp: now };
    }

    let bestMatch: { emotion: MeetingEmotion; confidence: number; intensity: number } = {
      emotion: MeetingEmotion.NEUTRAL,
      confidence: 0,
      intensity: 0
    };

    // 遍历所有情绪配置，计算匹配度
    this.EMOTION_CONFIG.forEach((config, emotion) => {
      // 检查冷却期
      const lastTime = this.lastEmotionTime.get(emotion) || 0;
      if (now - lastTime < config.cooldown) return;

      let matchScore = 0;
      let totalWeight = 0;

      // 计算 BlendShape 匹配度
      Object.entries(config.blendShapes).forEach(([key, threshold]) => {
        const value = (blendShapes as any)[key] || 0;
        const normalized = Math.min(value / threshold, 1.0);
        matchScore += normalized * config.weight;
        totalWeight += config.weight;
      });

      // 计算头部姿态匹配度
      if (config.headPose && headPose) {
        if (config.headPose.pitch && headPose.pitch > config.headPose.pitch) {
          matchScore += config.weight * 0.5;
          totalWeight += config.weight * 0.5;
        }
        if (config.headPose.yaw && Math.abs(headPose.yaw) > config.headPose.yaw) {
          matchScore += config.weight * 0.5;
          totalWeight += config.weight * 0.5;
        }
      }

      const confidence = totalWeight > 0 ? matchScore / totalWeight : 0;
      const intensity = matchScore / Object.keys(config.blendShapes).length;

      if (confidence > bestMatch.confidence && confidence > 0.5) {
        bestMatch = { emotion, confidence, intensity };
      }
    });

    // 更新最后触发时间
    if (bestMatch.confidence > 0.5) {
      this.lastEmotionTime.set(bestMatch.emotion, now);
    }

    const result: EmotionResult = {
      emotion: bestMatch.confidence > 0.5 ? bestMatch.emotion : MeetingEmotion.NEUTRAL,
      confidence: bestMatch.confidence,
      intensity: bestMatch.intensity,
      timestamp: now
    };

    // 记录历史
    this.emotionHistory.push(result);
    if (this.emotionHistory.length > 100) {
      this.emotionHistory.shift();
    }

    return result;
  }

  /**
   * 获取会议情绪统计
   */
  getEmotionStatistics(): Map<MeetingEmotion, number> {
    const stats = new Map<MeetingEmotion, number>();
    const recentEmotions = this.emotionHistory.filter(
      e => Date.now() - e.timestamp < 60000
    );

    recentEmotions.forEach(e => {
      stats.set(e.emotion, (stats.get(e.emotion) || 0) + e.intensity);
    });

    return stats;
  }

  /**
   * 获取会议共识度
   */
  getConsensusLevel(): number {
    const stats = this.getEmotionStatistics();
    const agree = stats.get(MeetingEmotion.AGREE) || 0;
    const disagree = stats.get(MeetingEmotion.DISAGREE) || 0;
    const total = agree + disagree;

    if (total === 0) return 0.5;
    return agree / total;
  }

  reset(): void {
    this.emotionHistory = [];
    this.lastEmotionTime.clear();
  }
}

4.2 Body AR 手势标注引擎（GestureAnnotationEngine.ets）

代码亮点：将 Body AR 骨骼关键点映射为白板坐标，支持隔空指向、圈选、翻页等协作手势。

// entry/src/main/ets/engine/GestureAnnotationEngine.ets
import { arEngine } from '@hms.core.ar.arengine';

export interface WhiteboardPoint {
  x: number;    // 0-1 归一化坐标
  y: number;
  type: 'move' | 'down' | 'up' | 'select';
  pressure: number;
}

export interface GestureCommand {
  type: 'cursor' | 'select' | 'draw' | 'flip' | 'zoom';
  points: WhiteboardPoint[];
  metadata: { [key: string]: any };
}

export class GestureAnnotationEngine {
  private static instance: GestureAnnotationEngine;

  private lastRightWrist: { x: number; y: number; z: number } | null = null;
  private lastLeftWrist: { x: number; y: number; z: number } | null = null;
  private lastGestureTime: number = 0;
  private readonly GESTURE_COOLDOWN = 500;

  // 手势状态机
  private gestureState: 'idle' | 'pointing' | 'selecting' | 'drawing' = 'idle';

  static getInstance(): GestureAnnotationEngine {
    if (!GestureAnnotationEngine.instance) {
      GestureAnnotationEngine.instance = new GestureAnnotationEngine();
    }
    return GestureAnnotationEngine.instance;
  }

  /**
   * 处理 Body AR 数据，生成白板手势命令
   */
  processBodyFrame(body: arEngine.ARBody): GestureCommand | null {
    const landmarks = body.getLandmarks3D();
    if (!landmarks) return null;

    const floatView = new Float32Array(landmarks);
    const now = Date.now();

    // 获取双手关键点
    const rightWrist = this.getLandmark3D(floatView, arEngine.ARBodyLandmarkType.RIGHT_WRIST);
    const rightIndex = this.getLandmark3D(floatView, arEngine.ARBodyLandmarkType.RIGHT_INDEX_FINGER_TIP);
    const leftWrist = this.getLandmark3D(floatView, arEngine.ARBodyLandmarkType.LEFT_WRIST);
    const leftIndex = this.getLandmark3D(floatView, arEngine.ARBodyLandmarkType.LEFT_INDEX_FINGER_TIP);

    if (!rightWrist || !rightIndex) return null;

    // 计算右手食指指向的屏幕坐标（映射到白板）
    const cursorPoint = this.mapToWhiteboard(rightIndex);

    // 检测手势状态
    const handDistance = leftWrist ?
      Math.sqrt(Math.pow(rightWrist.x - leftWrist.x, 2) + Math.pow(rightWrist.y - leftWrist.y, 2)) : 0;

    // 状态机转换
    if (handDistance < 0.12 && leftWrist) {
      // 双手捏合 → 圈选模式
      this.gestureState = 'selecting';
      return this.createSelectCommand(rightIndex, leftIndex!);
    } else if (this.isFist(rightWrist, rightIndex, floatView)) {
      // 握拳 → 绘制模式
      this.gestureState = 'drawing';
      return this.createDrawCommand(cursorPoint);
    } else if (handDistance > 0.45 && leftWrist) {
      // 双手张开 → 缩放
      return this.createZoomCommand(handDistance);
    } else if (this.detectSwipe(rightWrist)) {
      // 挥手 → 翻页
      if (now - this.lastGestureTime > this.GESTURE_COOLDOWN) {
        this.lastGestureTime = now;
        return { type: 'flip', points: [], metadata: { direction: 'next' } };
      }
    }

    // 默认：指向模式
    this.gestureState = 'pointing';
    return this.createCursorCommand(cursorPoint);

    // 更新历史位置
    this.lastRightWrist = rightWrist;
    this.lastLeftWrist = leftWrist;
  }

  private mapToWhiteboard(fingerTip: { x: number; y: number; z: number }): WhiteboardPoint {
    // 将 3D 空间坐标映射到白板 2D 坐标
    // 假设摄像头前方 0.5-1.5m 为有效交互区域
    const normalizedX = Math.max(0, Math.min(1, (fingerTip.x + 0.5) / 1.0));
    const normalizedY = Math.max(0, Math.min(1, (0.5 - fingerTip.y) / 1.0));

    return {
      x: normalizedX,
      y: normalizedY,
      type: 'move',
      pressure: Math.max(0, Math.min(1, 1.5 - fingerTip.z)) // 距离越近压力越大
    };
  }

  private isFist(
    wrist: { x: number; y: number; z: number },
    indexTip: { x: number; y: number; z: number },
    floatView: Float32Array
  ): boolean {
    // 检测是否握拳：食指指尖距离手腕较近
    const distance = Math.sqrt(
      Math.pow(indexTip.x - wrist.x, 2) +
      Math.pow(indexTip.y - wrist.y, 2)
    );
    return distance < 0.08;
  }

  private detectSwipe(currentWrist: { x: number; y: number; z: number }): boolean {
    if (!this.lastRightWrist) return false;

    const velocity = Math.sqrt(
      Math.pow(currentWrist.x - this.lastRightWrist.x, 2) +
      Math.pow(currentWrist.y - this.lastRightWrist.y, 2)
    );

    // 速度阈值判定挥手
    return velocity > 0.3;
  }

  private createCursorCommand(point: WhiteboardPoint): GestureCommand {
    return {
      type: 'cursor',
      points: [point],
      metadata: { state: this.gestureState }
    };
  }

  private createDrawCommand(point: WhiteboardPoint): GestureCommand {
    return {
      type: 'draw',
      points: [{ ...point, type: 'down' }, point, { ...point, type: 'up' }],
      metadata: { strokeWidth: 2 + point.pressure * 4 }
    };
  }

  private createSelectCommand(p1: { x: number; y: number }, p2: { x: number; y: number }): GestureCommand {
    const rect = {
      x: Math.min(p1.x, p2.x),
      y: Math.min(p1.y, p2.y),
      width: Math.abs(p1.x - p2.x),
      height: Math.abs(p1.y - p2.y)
    };

    return {
      type: 'select',
      points: [
        { x: rect.x, y: rect.y, type: 'down', pressure: 1 },
        { x: rect.x + rect.width, y: rect.y + rect.height, type: 'up', pressure: 1 }
      ],
      metadata: { selection: rect }
    };
  }

  private createZoomCommand(handDistance: number): GestureCommand {
    return {
      type: 'zoom',
      points: [],
      metadata: { scale: 1 + (handDistance - 0.45) * 2 }
    };
  }

  private getLandmark3D(floatView: Float32Array, type: arEngine.ARBodyLandmarkType): { x: number; y: number; z: number } | null {
    const index = Object.values(arEngine.ARBodyLandmarkType).indexOf(type);
    if (index < 0) return null;
    const offset = index * 3;
    if (offset + 2 >= floatView.length) return null;
    return {
      x: floatView[offset],
      y: floatView[offset + 1],
      z: floatView[offset + 2]
    };
  }

  reset(): void {
    this.gestureState = 'idle';
    this.lastRightWrist = null;
    this.lastLeftWrist = null;
  }
}

4.3 沉浸光感情绪标题栏（EmotionLightTitleBar.ets）

代码亮点：根据会议情绪统计动态调整光效颜色和脉冲频率，发言者高亮显示。

// entry/src/main/ets/components/EmotionLightTitleBar.ets
import { HdsNavigation, SystemMaterialEffect } from '@kit.UIDesignKit';
import { EmotionRecognitionEngine, MeetingEmotion } from '../engine/EmotionRecognitionEngine';

@Component
export struct EmotionLightTitleBar {
  @Prop meetingTitle: string = '产品评审会议';
  @Prop participantCount: number = 5;
  @Prop speakerName: string = '';
  @State consensusLevel: number = 0.5;
  @State dominantEmotion: MeetingEmotion = MeetingEmotion.NEUTRAL;
  @State emotionStats: Map<MeetingEmotion, number> = new Map();
  @State pulsePhase: number = 0;

  private emotionEngine: EmotionRecognitionEngine = EmotionRecognitionEngine.getInstance();

  aboutToAppear(): void {
    this.startEmotionMonitoring();
    this.startPulseAnimation();
  }

  private startEmotionMonitoring(): void {
    setInterval(() => {
      this.emotionStats = this.emotionEngine.getEmotionStatistics();
      this.consensusLevel = this.emotionEngine.getConsensusLevel();
      this.dominantEmotion = this.getDominantEmotion();
    }, 1000);
  }

  private startPulseAnimation(): void {
    const animate = () => {
      this.pulsePhase = (this.pulsePhase + 0.03) % (Math.PI * 2);
      requestAnimationFrame(animate);
    };
    requestAnimationFrame(animate);
  }

  private getDominantEmotion(): MeetingEmotion {
    let maxIntensity = 0;
    let dominant = MeetingEmotion.NEUTRAL;

    this.emotionStats.forEach((intensity, emotion) => {
      if (intensity > maxIntensity && emotion !== MeetingEmotion.NEUTRAL) {
        maxIntensity = intensity;
        dominant = emotion;
      }
    });

    return dominant;
  }

  private getEmotionColor(): string {
    const colors: Map<MeetingEmotion, string> = new Map([
      [MeetingEmotion.AGREE, '#00D4AA'],
      [MeetingEmotion.DISAGREE, '#FF6B6B'],
      [MeetingEmotion.QUESTION, '#9B59B6'],
      [MeetingEmotion.SURPRISE, '#FFE66D'],
      [MeetingEmotion.LIKE, '#4ECDC4'],
      [MeetingEmotion.NEUTRAL, '#808080']
    ]);
    return colors.get(this.dominantEmotion) || '#808080';
  }

  private getMeetingStatus(): string {
    if (this.consensusLevel > 0.8) return '高度共识';
    if (this.consensusLevel > 0.6) return '多数赞同';
    if (this.consensusLevel < 0.4) return '存在分歧';
    if (this.emotionStats.get(MeetingEmotion.QUESTION)! > 0.3) return '疑问集中';
    return '讨论中';
  }

  build() {
    HdsNavigation({
      title: this.meetingTitle,
      subtitle: `${this.participantCount}人参与 · ${this.getMeetingStatus()}`,
      systemMaterialEffect: SystemMaterialEffect.IMMERSIVE,
      backgroundOpacity: 0.85,
      height: 56,
      leading: this.buildLeadingActions(),
      trailing: this.buildTrailingActions()
    })
    .width('100%')
    .backgroundColor(`rgba(${this.hexToRgb(this.getEmotionColor())}, 0.15)`)
    .border({
      width: { bottom: 2 },
      color: this.getEmotionColor()
    })
    .shadow({
      radius: 10 + Math.sin(this.pulsePhase) * 6,
      color: this.getEmotionColor(),
      offsetX: 0,
      offsetY: 2
    })
    .animation({
      duration: 300,
      curve: Curve.EaseInOut
    })
  }

  @Builder
  buildLeadingActions(): void {
    Row({ space: 12 }) {
      // 情绪状态指示灯
      Stack() {
        Circle()
          .width(14)
          .height(14)
          .fill(this.getEmotionColor())
          .opacity(0.3 + Math.sin(this.pulsePhase) * 0.2)

        Circle()
          .width(8)
          .height(8)
          .fill(this.getEmotionColor())
      }

      // 共识度指示
      Column({ space: 2 }) {
        Text(`${Math.round(this.consensusLevel * 100)}% 共识`)
          .fontSize(13)
          .fontColor(this.consensusLevel > 0.6 ? '#00D4AA' : '#FFD700')
          .fontWeight(FontWeight.Bold)

        // 共识度进度条
        Row() {
          Row()
            .width(`${this.consensusLevel * 100}%`)
            .height(3)
            .backgroundColor(this.consensusLevel > 0.6 ? '#00D4AA' : '#FFD700')
            .borderRadius(1.5)
        }
        .width(60)
        .height(3)
        .backgroundColor('rgba(255,255,255,0.2)')
        .borderRadius(1.5)
      }
    }
    .padding({ left: 16 })
  }

  @Builder
  buildTrailingActions(): void {
    Row({ space: 10 }) {
      // 当前发言者
      if (this.speakerName) {
        Text(`🎤 ${this.speakerName}`)
          .fontSize(12)
          .fontColor('#FFFFFF')
          .padding({ left: 10, right: 10, top: 4, bottom: 4 })
          .backgroundColor('rgba(255,255,255,0.15)')
          .borderRadius(12)
      }

      // 情绪统计迷你面板
      Row({ space: 4 }) {
        ForEach([
          { emotion: MeetingEmotion.AGREE, icon: '✓', count: this.emotionStats.get(MeetingEmotion.AGREE) || 0 },
          { emotion: MeetingEmotion.DISAGREE, icon: '✗', count: this.emotionStats.get(MeetingEmotion.DISAGREE) || 0 },
          { emotion: MeetingEmotion.QUESTION, icon: '?', count: this.emotionStats.get(MeetingEmotion.QUESTION) || 0 }
        ], (item: { emotion: MeetingEmotion; icon: string; count: number }) => {
          if (item.count > 0) {
            Text(`${item.icon} ${Math.round(item.count)}`)
              .fontSize(11)
              .fontColor('rgba(255,255,255,0.7)')
              .padding({ left: 6, right: 6, top: 2, bottom: 2 })
              .backgroundColor('rgba(255,255,255,0.1)')
              .borderRadius(6)
          }
        })
      }
    }
    .padding({ right: 16 })
  }

  private hexToRgb(hex: string): string {
    const r = parseInt(hex.slice(1, 3), 16);
    const g = parseInt(hex.slice(3, 5), 16);
    const b = parseInt(hex.slice(5, 7), 16);
    return `${r},${g},${b}`;
  }
}

4.4 悬浮协作面板（FloatCollaborationPanel.ets）

代码亮点：底部悬浮面板显示参会者情绪统计、手势模式和白板工具，支持透明度调节。

// entry/src/main/ets/components/FloatCollaborationPanel.ets
import { HdsTabs, HdsTabsController, hdsMaterial } from '@kit.UIDesignKit';
import { EmotionRecognitionEngine, MeetingEmotion } from '../engine/EmotionRecognitionEngine';

@Component
export struct FloatCollaborationPanel {
  @State currentTab: number = 0;
  @State transparencyLevel: number = 0.75;
  @State gestureMode: string = 'cursor';
  @Prop emotionStats: Map<MeetingEmotion, number> = new Map();
  private controller: HdsTabsController = new HdsTabsController();

  private readonly TAB_CONFIG = [
    { label: '情绪', icon: $r('sys.symbol.face_smiling') },
    { label: '手势', icon: $r('sys.symbol.hand_raised') },
    { label: '白板', icon: $r('sys.symbol.pencil') },
    { label: '设置', icon: $r('sys.symbol.gear') }
  ];

  build() {
    HdsTabs({ controller: this.controller }) {
      ForEach(this.TAB_CONFIG, (item: typeof this.TAB_CONFIG[0], index: number) => {
        TabContent() {
          this.buildTabContent(index)
        }
        .tabBar(new BottomTabBarStyle({
          normal: new SymbolGlyphModifier(item.icon).fontColor(['rgba(255,255,255,0.5)']),
          selected: new SymbolGlyphModifier(item.icon).fontColor(['#00D4AA'])
        }, item.label))
      })
    }
    .barOverlap(true)
    .vertical(false)
    .barPosition(BarPosition.End)
    .barFloatingStyle({
      barBottomMargin: 20,
      barSideMargin: 40,
      systemMaterialEffect: {
        materialType: hdsMaterial.MaterialType.IMMERSIVE,
        materialLevel: hdsMaterial.MaterialLevel.EXQUISITE
      }
    })
    .backgroundColor(`rgba(12,12,22,${this.transparencyLevel})`)
    .backdropFilter($r('sys.blur.40'))
    .borderRadius(24)
    .margin({ left: '4%', right: '4%', bottom: 14 })
    .shadow({
      radius: 24,
      color: 'rgba(0,0,0,0.35)',
      offsetX: 0,
      offsetY: -4
    })
  }

  @Builder
  buildTabContent(index: number): void {
    Column({ space: 12 }) {
      if (index === 0) {
        this.buildEmotionPanel()
      } else if (index === 1) {
        this.buildGesturePanel()
      } else if (index === 2) {
        this.buildWhiteboardPanel()
      } else {
        this.buildSettingsPanel()
      }
    }
    .width('100%')
    .height('100%')
    .padding(16)
  }

  @Builder
  buildEmotionPanel(): void {
    Column({ space: 10 }) {
      Text('实时情绪统计')
        .fontSize(16)
        .fontColor('#FFFFFF')
        .fontWeight(FontWeight.Bold)

      // 情绪分布条形图
      Column({ space: 8 }) {
        ForEach([
          { emotion: MeetingEmotion.AGREE, label: '赞同', color: '#00D4AA', icon: '✓' },
          { emotion: MeetingEmotion.DISAGREE, label: '反对', color: '#FF6B6B', icon: '✗' },
          { emotion: MeetingEmotion.QUESTION, label: '疑问', color: '#9B59B6', icon: '?' },
          { emotion: MeetingEmotion.SURPRISE, label: '惊讶', color: '#FFE66D', icon: '!' },
          { emotion: MeetingEmotion.LIKE, label: '喜欢', color: '#4ECDC4', icon: '♥' }
        ], (item: { emotion: MeetingEmotion; label: string; color: string; icon: string }) => {
          const count = this.emotionStats.get(item.emotion) || 0;
          const maxCount = Math.max(...Array.from(this.emotionStats.values()), 1);
          const percentage = (count / maxCount) * 100;

          Row({ space: 8 }) {
            Text(`${item.icon} ${item.label}`)
              .fontSize(13)
              .fontColor('rgba(255,255,255,0.8)')
              .width(60)

            Stack({ alignContent: Alignment.Start }) {
              Row()
                .width(`${percentage}%`)
                .height(8)
                .backgroundColor(item.color)
                .borderRadius(4)
                .animation({ duration: 500 })

              Row()
                .width('100%')
                .height(8)
                .backgroundColor('rgba(255,255,255,0.1)')
                .borderRadius(4)
            }
            .width(120)
            .height(8)

            Text(`${Math.round(count)}`)
              .fontSize(12)
              .fontColor(item.color)
              .width(30)
          }
          .width('100%')
        })
      }

      // 情绪趋势提示
      Text('最近1分钟情绪趋势')
        .fontSize(12)
        .fontColor('rgba(255,255,255,0.5)')
        .margin({ top: 4 })
    }
  }

  @Builder
  buildGesturePanel(): void {
    Column({ space: 10 }) {
      Text('手势控制模式')
        .fontSize(16)
        .fontColor('#FFFFFF')
        .fontWeight(FontWeight.Bold)

      // 当前模式指示
      Row({ space: 8 }) {
        ForEach([
          { mode: 'cursor', label: '指针', icon: '👆' },
          { mode: 'draw', label: '绘制', icon: '✏️' },
          { mode: 'select', label: '圈选', icon: '⬚' }
        ], (item: { mode: string; label: string; icon: string }) => {
          Column({ space: 4 }) {
            Text(item.icon)
              .fontSize(24)

            Text(item.label)
              .fontSize(12)
              .fontColor(this.gestureMode === item.mode ? '#00D4AA' : 'rgba(255,255,255,0.5)')
          }
          .width(70)
          .padding(10)
          .backgroundColor(this.gestureMode === item.mode ? 'rgba(0,212,170,0.15)' : 'rgba(255,255,255,0.05)')
          .borderRadius(12)
          .border({
            width: 1,
            color: this.gestureMode === item.mode ? '#00D4AA' : 'transparent'
          })
          .onClick(() => {
            this.gestureMode = item.mode;
            AppStorage.setOrCreate('gesture_mode', item.mode);
          })
        })
      }

      // 手势指南
      Column({ space: 6 }) {
        ForEach([
          { gesture: '👆 食指指向', desc: '移动光标位置' },
          { gesture: '✊ 握拳', desc: '进入绘制模式' },
          { gesture: '🤏 双手捏合', desc: '圈选区域' },
          { gesture: '🙌 双手张开', desc: '放大白板' },
          { gesture: '👋 挥手', desc: '翻到下页' }
        ], (item: { gesture: string; desc: string }) => {
          Row({ space: 10 }) {
            Text(item.gesture)
              .fontSize(16)

            Text(item.desc)
              .fontSize(12)
              .fontColor('rgba(255,255,255,0.6)')
              .layoutWeight(1)
          }
          .width('100%')
          .padding(6)
        })
      }
      .padding(10)
      .backgroundColor('rgba(255,255,255,0.03)')
      .borderRadius(8)
    }
  }

  @Builder
  buildWhiteboardPanel(): void {
    Column({ space: 10 }) {
      Text('白板工具')
        .fontSize(16)
        .fontColor('#FFFFFF')
        .fontWeight(FontWeight.Bold)

      Grid() {
        ForEach([
          { tool: 'pen', icon: '✏️', color: '#FFFFFF' },
          { tool: 'marker', icon: '🖍️', color: '#FFE66D' },
          { tool: 'eraser', icon: '🧼', color: '#FF6B6B' },
          { tool: 'shape', icon: '⬜', color: '#4ECDC4' },
          { tool: 'text', icon: 'T', color: '#9B59B6' },
          { tool: 'undo', icon: '↩️', color: '#808080' }
        ], (item: { tool: string; icon: string; color: string }) => {
          GridItem() {
            Column({ space: 6 }) {
              Text(item.icon)
                .fontSize(22)

              Text(item.tool)
                .fontSize(11)
                .fontColor('rgba(255,255,255,0.7)')
            }
            .width(60)
            .height(60)
            .backgroundColor('rgba(255,255,255,0.05)')
            .borderRadius(12)
          }
          .onClick(() => {
            AppStorage.setOrCreate('whiteboard_tool', item.tool);
          })
        })
      }
      .columnsTemplate('1fr 1fr 1fr')
      .rowsGap(10)
      .columnsGap(10)
    }
  }

  @Builder
  buildSettingsPanel(): void {
    Column({ space: 14 }) {
      Text('面板透明度')
        .fontSize(16)
        .fontColor('#FFFFFF')
        .fontWeight(FontWeight.Bold)

      Row({ space: 10 }) {
        ForEach([
          { label: '弱', value: 0.55 },
          { label: '平衡', value: 0.75 },
          { label: '强', value: 0.90 }
        ], (item: { label: string; value: number }) => {
          Button(item.label)
            .fontSize(13)
            .fontColor('#FFFFFF')
            .backgroundColor(this.transparencyLevel === item.value ? '#00D4AA' : 'rgba(255,255,255,0.1)')
            .padding({ left: 20, right: 20, top: 6, bottom: 6 })
            .borderRadius(16)
            .onClick(() => {
              this.transparencyLevel = item.value;
            })
        })
      }

      Text('情绪反馈灵敏度')
        .fontSize(16)
        .fontColor('#FFFFFF')
        .fontWeight(FontWeight.Bold)
        .margin({ top: 8 })

      Slider({
        value: 0.7,
        min: 0.3,
        max: 1.0,
        step: 0.1
      })
      .width('100%')
      .selectedColor('#00D4AA')
    }
  }
}

4.5 主协作页面（CollaborationPage.ets）

代码亮点：整合 Face AR 情绪识别、Body AR 手势标注、沉浸光感标题栏和悬浮协作面板，实现完整的"AR 远程协作"体验。

// entry/src/main/ets/pages/CollaborationPage.ets
import { EmotionLightTitleBar } from '../components/EmotionLightTitleBar';
import { FloatCollaborationPanel } from '../components/FloatCollaborationPanel';
import { EmotionRecognitionEngine, EmotionResult, MeetingEmotion } from '../engine/EmotionRecognitionEngine';
import { GestureAnnotationEngine, GestureCommand } from '../engine/GestureAnnotationEngine';

@Entry
@Component
struct CollaborationPage {
  @State meetingTitle: string = 'Q3产品规划评审';
  @State participantCount: number = 8;
  @State speakerName: string = '产品经理-张三';
  @State emotionStats: Map<MeetingEmotion, number> = new Map();
  @State whiteboardContent: string = '白板内容区域';
  @State cursorPosition: { x: number; y: number } = { x: 0.5, y: 0.5 };
  @State isDrawing: boolean = false;
  @State trackingQuality: number = 1.0;

  private emotionEngine: EmotionRecognitionEngine = EmotionRecognitionEngine.getInstance();
  private gestureEngine: GestureAnnotationEngine = GestureAnnotationEngine.getInstance();
  private arLoopId: number = 0;

  aboutToAppear(): void {
    this.initializeARSession();
  }

  aboutToDisappear(): void {
    cancelAnimationFrame(this.arLoopId);
  }

  private initializeARSession(): void {
    this.startARLoop();
  }

  private startARLoop(): void {
    const loop = () => {
      this.processARFrame();
      this.arLoopId = requestAnimationFrame(loop);
    };
    this.arLoopId = requestAnimationFrame(loop);
  }

  private processARFrame(): void {
    // 模拟AR数据处理
    let quality = 0;

    // Face AR情绪处理
    // const emotionResult = this.emotionEngine.recognizeEmotion(face);
    // if (emotionResult.confidence > 0.5) {
    //   this.handleEmotion(emotionResult);
    // }
    // quality += 0.5;

    // Body AR手势处理
    // const gestureCommand = this.gestureEngine.processBodyFrame(body);
    // if (gestureCommand) {
    //   this.handleGesture(gestureCommand);
    // }
    // quality += 0.5;

    // 模拟数据
    this.simulateCollaborationData();

    this.trackingQuality = quality;
    this.emotionStats = this.emotionEngine.getEmotionStatistics();
  }

  private simulateCollaborationData(): void {
    // 模拟光标移动
    this.cursorPosition = {
      x: 0.3 + Math.sin(Date.now() / 2000) * 0.2,
      y: 0.3 + Math.cos(Date.now() / 3000) * 0.2
    };
  }

  private handleEmotion(result: EmotionResult): void {
    // 广播情绪到远端
    console.info(`[Emotion] ${result.emotion} (confidence: ${result.confidence})`);

    // 本地反馈
    if (result.emotion === MeetingEmotion.QUESTION) {
      this.showQuestionIndicator();
    }
  }

  private handleGesture(command: GestureCommand): void {
    switch (command.type) {
      case 'cursor':
        if (command.points.length > 0) {
          this.cursorPosition = { x: command.points[0].x, y: command.points[0].y };
        }
        break;
      case 'draw':
        this.isDrawing = true;
        setTimeout(() => { this.isDrawing = false; }, 500);
        break;
      case 'select':
        console.info('[Gesture] Selection:', command.metadata.selection);
        break;
      case 'flip':
        // 翻页逻辑
        break;
      case 'zoom':
        // 缩放逻辑
        break;
    }
  }

  private showQuestionIndicator(): void {
    // 显示疑问标记动画
  }

  build() {
    Stack({ alignContent: Alignment.Center }) {
      // 第一层：动态环境光背景
      this.buildAmbientLightLayer()

      // 第二层：协作内容层
      Column({ space: 0 }) {
        // 沉浸光感情绪标题栏
        EmotionLightTitleBar({
          meetingTitle: this.meetingTitle,
          participantCount: this.participantCount,
          speakerName: this.speakerName
        })

        // 白板区域
        Stack({ alignContent: Alignment.Center }) {
          // 白板背景
          Column() {
            Text(this.whiteboardContent)
              .fontSize(18)
              .fontColor('rgba(255,255,255,0.5)')

            // 手势光标
            Column()
              .width(20)
              .height(20)
              .backgroundColor(this.isDrawing ? '#FFE66D' : '#00D4AA')
              .borderRadius(10)
              .opacity(0.8)
              .position({
                x: `${this.cursorPosition.x * 100}%`,
                y: `${this.cursorPosition.y * 100}%`
              })
              .markAnchor({ x: 0.5, y: 0.5 })
              .shadow({
                radius: 10,
                color: this.isDrawing ? '#FFE66D' : '#00D4AA'
              })
              .animation({
                duration: 100,
                curve: Curve.Linear
              })

            // AR追踪状态
            if (this.trackingQuality > 0.5) {
              Text('AR协作中...')
                .fontSize(12)
                .fontColor('#00D4AA')
                .position({ x: '50%', y: '95%' })
                .markAnchor({ x: 0.5, y: 1 })
            }
          }
          .width('100%')
          .layoutWeight(1)
          .justifyContent(FlexAlign.Center)
          .backgroundColor('rgba(255,255,255,0.02)')
          .borderRadius(16)
          .margin(16)
          .border({
            width: 1,
            color: 'rgba(255,255,255,0.1)'
          })

          // 情绪浮动标记
          this.buildFloatingEmotionMarks()
        }
        .layoutWeight(1)
      }
      .width('100%')
      .height('100%')

      // 第三层：悬浮协作面板
      FloatCollaborationPanel({
        emotionStats: this.emotionStats
      })
      .height(300)
      .position({ x: 0, y: '100%' })
      .markAnchor({ x: 0, y: 1 })
    }
    .width('100%')
    .height('100%')
    .backgroundColor('#080810')
    .expandSafeArea(
      [SafeAreaType.SYSTEM],
      [SafeAreaEdge.TOP, SafeAreaEdge.BOTTOM, SafeAreaEdge.START, SafeAreaEdge.END]
    )
  }

  @Builder
  buildAmbientLightLayer(): void {
    Column() {
      // 顶部情绪光晕
      Column()
        .width(700)
        .height(350)
        .backgroundColor(this.getDominantColor())
        .blur(200)
        .opacity(0.1)
        .position({ x: '50%', y: '0%' })
        .anchor('50%')
        .animation({
          duration: 6000,
          curve: Curve.EaseInOut,
          iterations: -1,
          playMode: PlayMode.Alternate
        })
        .scale({ x: 1.3, y: 1.0 })

      // 底部氛围光
      Column()
        .width('100%')
        .height(250)
        .backgroundColor(this.getDominantColor())
        .opacity(0.05)
        .blur(120)
        .position({ x: 0, y: '75%' })
        .linearGradient({
          direction: GradientDirection.Top,
          colors: [
            [this.getDominantColor(), 0.0],
            ['transparent', 1.0]
          ]
        })
    }
    .width('100%')
    .height('100%')
    .backgroundColor('#050508')
  }

  @Builder
  buildFloatingEmotionMarks(): void {
    // 浮动情绪标记（模拟其他参会者的情绪反馈）
    ForEach([
      { x: 0.2, y: 0.3, emotion: MeetingEmotion.AGREE, user: '李四' },
      { x: 0.7, y: 0.5, emotion: MeetingEmotion.QUESTION, user: '王五' },
      { x: 0.5, y: 0.8, emotion: MeetingEmotion.SURPRISE, user: '赵六' }
    ], (mark: { x: number; y: number; emotion: MeetingEmotion; user: string }) => {
      Column({ space: 2 }) {
        Text(this.getEmotionIcon(mark.emotion))
          .fontSize(20)

        Text(mark.user)
          .fontSize(10)
          .fontColor('rgba(255,255,255,0.6)')
      }
      .position({ x: `${mark.x * 100}%`, y: `${mark.y * 100}%` })
      .markAnchor({ x: 0.5, y: 0.5 })
      .padding(6)
      .backgroundColor('rgba(0,0,0,0.4)')
      .borderRadius(8)
      .backdropFilter($r('sys.blur.10'))
    })
  }

  private getDominantColor(): string {
    const colors: Map<MeetingEmotion, string> = new Map([
      [MeetingEmotion.AGREE, '#00D4AA'],
      [MeetingEmotion.DISAGREE, '#FF6B6B'],
      [MeetingEmotion.QUESTION, '#9B59B6'],
      [MeetingEmotion.SURPRISE, '#FFE66D'],
      [MeetingEmotion.LIKE, '#4ECDC4'],
      [MeetingEmotion.NEUTRAL, '#808080']
    ]);

    let dominant = MeetingEmotion.NEUTRAL;
    let maxCount = 0;
    this.emotionStats.forEach((count, emotion) => {
      if (count > maxCount) {
        maxCount = count;
        dominant = emotion;
      }
    });

    return colors.get(dominant) || '#808080';
  }

  private getEmotionIcon(emotion: MeetingEmotion): string {
    const icons: Map<MeetingEmotion, string> = new Map([
      [MeetingEmotion.AGREE, '✓'],
      [MeetingEmotion.DISAGREE, '✗'],
      [MeetingEmotion.QUESTION, '?'],
      [MeetingEmotion.SURPRISE, '!'],
      [MeetingEmotion.LIKE, '♥'],
      [MeetingEmotion.NEUTRAL, '○']
    ]);
    return icons.get(emotion) || '○';
  }
}

五、关键技术总结

5.1 Face AR 情绪识别技术

情绪	BlendShape 参数	头部姿态	置信度阈值	冷却期
赞同	mouthSmile > 0.3	pitch > 0.25	0.5	1500ms
反对	mouthFrown > 0.4	yaw > 0.35	0.5	1500ms
疑问	browDown > 0.4, mouthPucker > 0.3	-	0.5	2000ms
惊讶	browInnerUp > 0.6, eyeWide > 0.5	-	0.5	2000ms
喜欢	mouthSmile > 0.5, cheekSquint > 0.4	-	0.5	1000ms

5.2 Body AR 手势标注技术

手势	骨骼关键点计算	映射操作	交互区域
食指指向	indexTip 3D位置	光标移动	白板全区域
握拳	indexTip-wrist 距离 < 0.08m	绘制模式	当前光标位置
双手捏合	双腕距离 < 0.12m	圈选区域	双指包围区域
双手张开	双腕距离 > 0.45m	缩放视图	白板整体
挥手	wrist 速度 > 0.3	翻页	边缘触发区

5.3 沉浸光感与会议情绪联动

会议状态	共识度	主导情绪	标题栏光效	环境光色	触发动作
高度共识	>80%	赞同	稳定翠绿	青绿	通过决议
多数赞同	>60%	赞同	柔和青蓝	蓝绿	继续讨论
存在争议	40-60%	混合	渐强琥珀	暖黄	深入探讨
严重分歧	<40%	反对	急促赤红	暗红	暂停调解
疑问集中	-	疑问	呼吸紫蓝	紫色	补充说明
惊讶反馈	-	惊讶	脉冲明黄	金黄	记录亮点

六、分布式协作设计

6.1 情绪数据同步

// 通过鸿蒙分布式软总线广播情绪数据
import { distributedDataObject } from '@kit.DistributedServiceKit';

export class EmotionSyncManager {
  private syncObj: distributedDataObject.DistributedObject;

  constructor() {
    this.syncObj = distributedDataObject.create({
      emotions: new Map(),
      consensusLevel: 0.5,
      timestamp: 0
    });
    this.syncObj.setSessionId('meeting_emotion_sync');
  }

  broadcastEmotion(emotion: EmotionResult): void {
    this.syncObj.emotions.set(emotion.emotion,
      (this.syncObj.emotions.get(emotion.emotion) || 0) + emotion.intensity);
    this.syncObj.timestamp = Date.now();
  }

  subscribeRemoteEmotions(callback: (emotions: Map<MeetingEmotion, number>) => void): void {
    this.syncObj.on('change', () => {
      callback(this.syncObj.emotions);
    });
  }
}

6.2 手势坐标同步

// 实时同步手势坐标到远端白板
export class GestureSyncManager {
  broadcastGesture(command: GestureCommand): void {
    // 通过软总线发送手势命令
    const message = JSON.stringify({
      type: command.type,
      points: command.points,
      metadata: command.metadata,
      timestamp: Date.now()
    });

    // 发送到所有参会设备
    this.sendToAllParticipants(message);
  }
}

七、总结与展望

本文基于 HarmonyOS 6（API 23）的 Face AR & Body AR 能力，结合 沉浸光感 + 悬浮导航，完整实战了一款 PC 端"AR 远程协作白板"应用。核心创新点总结：

1. 表情驱动会议反馈：通过 Face AR 识别 5 种会议情绪，实时统计赞同/反对/疑问分布，让"沉默的大多数"被看见
2. 隔空手势标注：利用 Body AR 实现无接触式白板操作，演讲者无需鼠标即可圈画重点
3. 情绪光感氛围：根据会议共识度动态调整 UI 光效，让远程会议也有"现场感"
4. 悬浮协作面板：底部导航实时显示情绪统计和手势模式，支持透明度调节，不遮挡白板内容

未来扩展方向：

• AI 会议纪要：结合情绪数据和发言内容，自动生成带有"情绪标签"的智能会议纪要
• 3D 空间白板：利用 AR 空间锚点，实现多设备共享的 3D 立体白板协作
• 虚拟化身：将 Face AR 表情映射到虚拟化身，让远程会议更具"面对面"感
• 脑机接口融合：未来结合脑电波检测，实现"意念标注"的终极协作体验

---

转载自：https://blog.csdn.net/u014727709/article/details/134040742
欢迎 👍点赞✍评论⭐收藏，欢迎指正
