一、前言：当城市安全遇见鸿蒙智能体

城市应急管理面临信息碎片化、决策延迟、现场态势感知不足等痛点。传统指挥调度依赖二维地图与语音对讲，指挥员难以直观把握三维空间态势。HarmonyOS 6（API 23）带来的**悬浮导航（Float Navigation）与沉浸光感（Immersive Light Sensing）**能力，结合多智能体协同决策系统，让我们可以在AR空间中构建一个"应急指挥调度中心"——指挥员通过手势与语音指令，在真实场景中叠加虚拟态势信息，多个AI智能体实时分析灾情、推演方案、调度资源。

本文将完整展示如何基于HarmonyOS 6新特性，开发一款AR应急指挥调度中心应用。核心亮点包括：

1. 悬浮态势面板：在AR场景中悬浮显示多源信息面板，智能避让现场障碍物，支持手势拖拽与多指缩放
2. 沉浸光感预警：根据环境危险等级自动调节界面色温与警示光效，实现物理空间与数字空间的危险感知同步
3. 多智能体协同：部署指挥智能体、分析智能体、调度智能体，协同完成灾情研判与资源调配
4. 分布式指挥：基于鸿蒙分布式能力，多终端（手机、平板、AR眼镜、PC）协同进入同一指挥空间

---

二、技术架构与核心能力解析

2.1 系统架构设计

┌─────────────────────────────────────────────────────────────┐
│                    应用层 (Application Layer)                  │
│  ┌─────────────┐  ┌─────────────┐  ┌─────────────────────┐ │
│  │ AR态势沙盘   │  │ 悬浮指挥面板 │  │ 沉浸预警光效系统     │ │
│  │  (ARKit)    │  │ (FloatNav)  │  │  (AlertLight)       │ │
│  └─────────────┘  └─────────────┘  └─────────────────────┘ │
├─────────────────────────────────────────────────────────────┤
│                    智能体层 (Multi-Agent Layer)                │
│  ┌─────────────┐  ┌─────────────┐  ┌─────────────────────┐ │
│  │ 指挥决策智能体│  │ 灾情分析智能体│  │ 资源调度智能体       │ │
│  │  (Command)  │  │  (Analysis) │  │  (Dispatch)         │ │
│  └─────────────┘  └─────────────┘  └─────────────────────┘ │
├─────────────────────────────────────────────────────────────┤
│                    能力层 (Capability Layer)                   │
│  ┌──────────┐ ┌──────────┐ ┌──────────┐ ┌──────────────┐ │
│  │ AR引擎   │ │ 光感API   │ │ 悬浮组件  │ │ 分布式协同    │ │
│  │ (ARKit)  │ │(Ambient) │ │(FloatNav)│ │(Distributed) │ │
│  └──────────┘ └──────────┘ └──────────┘ └──────────────┘ │
├─────────────────────────────────────────────────────────────┤
│                    系统服务层 (System Service)                 │
│         HarmonyOS 6 Kernel + 分布式软总线 + AI推理框架        │
└─────────────────────────────────────────────────────────────┘

2.2 核心技术栈

技术模块	对应API/框架	功能说明
AR空间计算	ARKit (API 23增强)	空间锚定、场景理解、虚实融合
悬浮导航	FloatNavigation (API 23新增)	多面板悬浮、智能避让、手势交互
沉浸光感	AmbientLightEngine + AlertLight	环境感知与危险光效联动
多智能体	MultiAgentFramework	多智能体协同推理与决策
分布式协同	DistributedData + SoftBus	多终端实时数据同步

---

三、核心代码实战

3.1 悬浮态势面板：AR指挥中枢

HarmonyOS 6的FloatNavigation在应急场景中需要支持多面板并行显示——态势概览、资源清单、通信频道可同时悬浮，且互不遮挡。

代码亮点：支持多面板管理、碰撞避让、危险等级驱动的透明度与边框警示、手势多指操作。

// EmergencyFloatPanels.ets
// AR应急指挥多面板悬浮系统

import { ARScene, ARNode, ARPlane } from '@kit.ARKit';
import { FloatNavigation, FloatNavConfig, PanelGroup } from '@kit.FloatNavigation';
import { GestureDetector, GestureType } from '@kit.GestureKit';

@Component
export struct EmergencyCommandPanels {
  @State panels: Map<string, PanelState> = new Map([
    ['situation', { position: { x: 50, y: 100 }, size: { w: 320, h: 400 }, opacity: 0.9, zIndex: 1 }],
    ['resources', { position: { x: 400, y: 100 }, size: { w: 280, h: 350 }, opacity: 0.9, zIndex: 2 }],
    ['communication', { position: { x: 50, y: 520 }, size: { w: 300, h: 200 }, opacity: 0.9, zIndex: 3 }]
  ]);

  @State dangerLevel: DangerLevel = DangerLevel.NORMAL;
  @State activePanel: string = 'situation';

  // 面板组配置：智能避让与吸附
  private panelGroup: PanelGroup = new PanelGroup({
    margin: 15,               // 面板间距
    edgeSnap: true,           // 边缘吸附
    collisionAvoidance: true, // 启用碰撞避让
    dangerAdaptive: true,     // 危险等级自适应
    minOpacity: 0.4,         // 危险时最小透明度
    alertBorder: true         // 启用警示边框
  });

  build() {
    Stack() {
      // 多面板容器
      ForEach(Array.from(this.panels.entries()), (entry: [string, PanelState]) => {
        const [panelId, state] = entry;

        FloatNavigation({
          id: panelId,
          group: this.panelGroup,
          position: state.position,
          size: state.size,
          zIndex: state.zIndex,
          onPositionChange: (pos: Position) => {
            this.updatePanelPosition(panelId, pos);
          },
          onCollision: (otherId: string) => {
            // 碰撞时自动调整位置
            this.resolveCollision(panelId, otherId);
          }
        }) {
          this.buildPanelContent(panelId, state);
        }
        .border({
          width: this.getDangerBorderWidth(),
          color: this.getDangerBorderColor(),
          radius: 12
        })
        .backgroundColor(`rgba(18, 18, 20, ${this.calculateOpacity(state)})`)
        .backdropBlur(25)
      });

      // 全局危险等级指示器（悬浮于所有面板之上）
      DangerLevelIndicator({
        level: this.dangerLevel,
        onLevelChange: (level: DangerLevel) => {
          this.dangerLevel = level;
          this.updatePanelsByDangerLevel(level);
        }
      })
      .position({ x: 20, y: 20 })
      .zIndex(100);
    }
    .width('100%')
    .height('100%');
  }

  // 构建面板内容
  @Builder
  buildPanelContent(panelId: string, state: PanelState) {
    switch (panelId) {
      case 'situation':
        SituationPanel({
          onDetailRequest: (area: string) => this.showAreaDetail(area),
          onAlertTrigger: (level: DangerLevel) => this.triggerAlert(level)
        });
        break;
      case 'resources':
        ResourcePanel({
          onDispatchRequest: (resource: ResourceUnit) => this.dispatchResource(resource),
          onStatusUpdate: (id: string, status: ResourceStatus) => this.updateResourceStatus(id, status)
        });
        break;
      case 'communication':
        CommunicationPanel({
          onChannelSelect: (channel: CommChannel) => this.switchChannel(channel),
          onEmergencyBroadcast: (msg: string) => this.broadcastEmergency(msg)
        });
        break;
    }
  }

  // 根据危险等级计算面板透明度
  private calculateOpacity(state: PanelState): number {
    if (this.dangerLevel === DangerLevel.CRITICAL) {
      // 紧急状态：降低面板透明度，确保现场视野
      return Math.max(state.opacity * 0.5, this.panelGroup.config.minOpacity);
    } else if (this.dangerLevel === DangerLevel.WARNING) {
      return Math.max(state.opacity * 0.75, 0.6);
    }
    return state.opacity;
  }

  // 危险等级边框宽度
  private getDangerBorderWidth(): number {
    switch (this.dangerLevel) {
      case DangerLevel.CRITICAL: return 3;
      case DangerLevel.WARNING: return 2;
      default: return 1;
    }
  }

  // 危险等级边框颜色
  private getDangerBorderColor(): string {
    switch (this.dangerLevel) {
      case DangerLevel.CRITICAL: return '#FF3B30';  // 红色
      case DangerLevel.WARNING: return '#FF9500';   // 橙色
      case DangerLevel.CAUTION: return '#FFCC00';   // 黄色
      default: return '#3A3A3C';                    // 默认深灰
    }
  }

  // 更新面板位置
  private updatePanelPosition(id: string, pos: Position): void {
    const state = this.panels.get(id);
    if (state) {
      state.position = pos;
      this.panels.set(id, state);

      // 同步AR空间坐标
      this.syncARPosition(id, pos);
    }
  }

  // 碰撞解析：自动调整位置避免重叠
  private resolveCollision(id1: string, id2: string): void {
    const state1 = this.panels.get(id1);
    const state2 = this.panels.get(id2);

    if (!state1 || !state2) return;

    // 计算重叠区域
    const overlapX = Math.max(0,
      Math.min(state1.position.x + state1.size.w, state2.position.x + state2.size.w) -
      Math.max(state1.position.x, state2.position.x)
    );
    const overlapY = Math.max(0,
      Math.min(state1.position.y + state1.size.h, state2.position.y + state2.size.h) -
      Math.max(state1.position.y, state2.position.y)
    );

    // 选择位移最小的方向分离
    if (overlapX < overlapY) {
      // 水平分离
      const center1 = state1.position.x + state1.size.w / 2;
      const center2 = state2.position.x + state2.size.w / 2;
      const direction = center1 < center2 ? -1 : 1;

      state1.position.x += direction * (overlapX + this.panelGroup.config.margin);
    } else {
      // 垂直分离
      const center1 = state1.position.y + state1.size.h / 2;
      const center2 = state2.position.y + state2.size.h / 2;
      const direction = center1 < center2 ? -1 : 1;

      state1.position.y += direction * (overlapY + this.panelGroup.config.margin);
    }

    this.panels.set(id1, state1);
  }

  // 危险等级变化时更新所有面板
  private updatePanelsByDangerLevel(level: DangerLevel): void {
    // 触发光效系统联动
    AlertLightSystem.getInstance().setDangerLevel(level);

    // 通知智能体更新决策策略
    CommandAgent.getInstance().updateDangerContext(level);
  }

  // 同步AR空间位置
  private syncARPosition(id: string, pos: Position): void {
    const arNode = ARScene.getNode(`panel_${id}`);
    if (arNode) {
      arNode.position = ARScene.screenToWorld(pos);
      arNode.billboardMode = BillboardMode.BILLBOARD_Y;
    }
  }

  // 触发警报
  private triggerAlert(level: DangerLevel): void {
    this.dangerLevel = level;
    this.updatePanelsByDangerLevel(level);

    // 启动紧急广播
    this.broadcastEmergency(`警报升级：当前危险等级为${level}`);
  }
}

// 类型定义
interface PanelState {
  position: Position;
  size: { w: number; h: number };
  opacity: number;
  zIndex: number;
}

enum DangerLevel {
  NORMAL = 'normal',
  CAUTION = 'caution',
  WARNING = 'warning',
  CRITICAL = 'critical'
}

3.2 沉浸预警光效：物理空间的危险感知

HarmonyOS 6的AlertLightSystem将数字预警信息转化为物理空间的光效反馈——当危险等级提升时，整个AR界面的色温、闪烁频率、边框光效都会同步变化，让指挥员无需注视屏幕即可感知态势变化。

代码亮点：环境光感知联动、危险等级光效映射、空间化警示光源、生理节律友好设计。

// AlertLightSystem.ets
// 沉浸预警光效系统：物理空间的危险感知

import { AmbientLightEngine, VirtualLight, LightType } from '@kit.AmbientLight';
import { ARScene, AREnvironment } from '@kit.ARKit';
import { sensor } from '@kit.SensorKit';
import { haptic } from '@kit.HapticKit';

export class AlertLightSystem {
  private static instance: AlertLightSystem;
  private lightEngine: AmbientLightEngine;
  private alertLights: VirtualLight[] = [];
  private currentLevel: DangerLevel = DangerLevel.NORMAL;
  private pulseInterval: number | null = null;
  private envLightBase: { intensity: number; colorTemp: number } = { intensity: 500, colorTemp: 6500 };

  // 危险等级光效配置
  private readonly ALERT_CONFIG: Record<DangerLevel, AlertConfig> = {
    [DangerLevel.NORMAL]: {
      baseColor: '#34C759',      // 绿色
      pulseColor: '#30D158',
      pulseFreq: 0,             // 常亮
      intensity: 1.0,
      borderFlash: false,
      hapticPattern: HapticType.NONE
    },
    [DangerLevel.CAUTION]: {
      baseColor: '#FFCC00',      // 黄色
      pulseColor: '#FFD60A',
      pulseFreq: 2000,          // 2秒闪烁
      intensity: 1.2,
      borderFlash: true,
      hapticPattern: HapticType.LIGHT
    },
    [DangerLevel.WARNING]: {
      baseColor: '#FF9500',      // 橙色
      pulseColor: '#FF9F0A',
      pulseFreq: 1000,          // 1秒闪烁
      intensity: 1.5,
      borderFlash: true,
      hapticPattern: HapticType.MEDIUM
    },
    [DangerLevel.CRITICAL]: {
      baseColor: '#FF3B30',      // 红色
      pulseColor: '#FF453A',
      pulseFreq: 500,           // 0.5秒闪烁
      intensity: 2.0,
      borderFlash: true,
      hapticPattern: HapticType.HEAVY
    }
  };

  private constructor() {
    this.lightEngine = new AmbientLightEngine({
      updateInterval: 50,  // 50ms高频更新
      hdrSupport: true
    });

    this.initAlertLights();
    this.startEnvironmentMonitoring();
  }

  static getInstance(): AlertLightSystem {
    if (!AlertLightSystem.instance) {
      AlertLightSystem.instance = new AlertLightSystem();
    }
    return AlertLightSystem.instance;
  }

  // 初始化警示光源系统
  private initAlertLights(): void {
    // 顶部环境警示光（模拟警灯效果）
    const topAlert = VirtualLight.create({
      type: LightType.DIRECTIONAL,
      intensity: 0,
      color: '#34C759',
      direction: { x: 0, y: -1, z: 0 },
      castShadow: false
    });

    // 底部氛围光（照亮指挥员手部区域）
    const bottomAmbient = VirtualLight.create({
      type: LightType.POINT,
      intensity: 0.3,
      color: '#FFFFFF',
      position: { x: 0, y: -0.5, z: 0.3 },
      castShadow: false
    });

    // 边缘轮廓光（面板边框发光效果）
    const rimAlert = VirtualLight.create({
      type: LightType.SPOT,
      intensity: 0,
      color: '#34C759',
      position: { x: 0, y: 0, z: 0.5 },
      direction: { x: 0, y: 0, z: -1 },
      spotAngle: 60,
      castShadow: false
    });

    this.alertLights = [topAlert, bottomAmbient, rimAlert];
    this.lightEngine.registerLights(this.alertLights);
  }

  // 启动环境光监测
  private async startEnvironmentMonitoring(): Promise<void> {
    const lightSensor = sensor.getLightSensor();

    setInterval(async () => {
      const data = await lightSensor.read();
      this.envLightBase = {
        intensity: data.intensity,
        colorTemp: data.colorTemperature
      };

      // 根据环境光调整基础亮度
      this.adjustBaseIntensity();
    }, 500);
  }

  // 设置危险等级并触发光效
  public setDangerLevel(level: DangerLevel): void {
    if (this.currentLevel === level) return;

    const oldLevel = this.currentLevel;
    this.currentLevel = level;

    const config = this.ALERT_CONFIG[level];

    // 1. 停止旧的光效脉冲
    this.stopPulse();

    // 2. 启动新的光效
    this.applyAlertConfig(config);

    // 3. 触发触觉反馈
    if (config.hapticPattern !== HapticType.NONE) {
      haptic.trigger(config.hapticPattern, {
        intensity: 1.0,
        sharpness: level === DangerLevel.CRITICAL ? 1.0 : 0.5
      });
    }

    // 4. 启动脉冲闪烁（如果需要）
    if (config.pulseFreq > 0) {
      this.startPulse(config);
    }

    // 5. 通知AR场景更新氛围
    this.updateAREnvironment(level);

    console.info(`[AlertLight] 危险等级变更: ${oldLevel} -> ${level}`);
  }

  // 应用警示配置
  private applyAlertConfig(config: AlertConfig): void {
    // 顶部警示光
    this.alertLights[0].color = config.baseColor;
    this.alertLights[0].intensity = config.intensity * 0.5;

    // 底部氛围光色温偏移
    const tempOffset = this.calculateTempOffset(config.baseColor);
    this.alertLights[1].color = this.adjustColorTemp(this.envLightBase.colorTemp + tempOffset);

    // 边缘轮廓光
    this.alertLights[2].color = config.baseColor;
    this.alertLights[2].intensity = config.intensity * 0.3;

    this.lightEngine.commitChanges();
  }

  // 启动脉冲闪烁
  private startPulse(config: AlertConfig): void {
    let isPulse = false;

    this.pulseInterval = setInterval(() => {
      isPulse = !isPulse;

      const targetColor = isPulse ? config.pulseColor : config.baseColor;
      const targetIntensity = isPulse ? config.intensity : config.intensity * 0.6;

      // 顶部光脉冲
      this.alertLights[0].color = targetColor;
      this.alertLights[0].intensity = targetIntensity * 0.5;

      // 边缘光脉冲
      this.alertLights[2].color = targetColor;
      this.alertLights[2].intensity = targetIntensity * 0.3;

      this.lightEngine.commitChanges();
    }, config.pulseFreq / 2);
  }

  // 停止脉冲
  private stopPulse(): void {
    if (this.pulseInterval) {
      clearInterval(this.pulseInterval);
      this.pulseInterval = null;
    }
  }

  // 更新AR环境氛围
  private updateAREnvironment(level: DangerLevel): void {
    const envConfig = this.ALERT_CONFIG[level];

    // 更新AR场景雾效颜色
    ARScene.setEnvironment({
      fogColor: this.hexToRGBA(envConfig.baseColor, 0.1),
      fogDensity: level === DangerLevel.CRITICAL ? 0.05 : 0.02
    });

    // 更新天空盒色调
    AREnvironment.setSkyboxTint(envConfig.baseColor, 0.15);
  }

  // 根据颜色计算色温偏移
  private calculateTempOffset(color: string): number {
    const rgb = this.hexToRGB(color);
    // 简单算法：红色偏暖（负偏移），绿色偏冷（正偏移）
    if (rgb.r > rgb.g && rgb.r > rgb.b) return -500;  // 暖色
    if (rgb.g > rgb.r && rgb.g > rgb.b) return 500;   // 冷色
    return 0;
  }

  // 调整基础亮度（确保在任何环境光下都可见）
  private adjustBaseIntensity(): void {
    const envIntensity = this.envLightBase.intensity;
    const scale = Math.max(1.0, 1000 / (envIntensity + 1)); // 环境越暗，警示光越强

    this.alertLights.forEach(light => {
      light.intensity *= scale;
    });

    this.lightEngine.commitChanges();
  }

  // 工具方法
  private hexToRGB(hex: string): { r: number; g: number; b: number } {
    const result = /^#?([a-f\d]{2})([a-f\d]{2})([a-f\d]{2})$/i.exec(hex);
    return result ? {
      r: parseInt(result[1], 16),
      g: parseInt(result[2], 16),
      b: parseInt(result[3], 16)
    } : { r: 0, g: 0, b: 0 };
  }

  private hexToRGBA(hex: string, alpha: number): string {
    const rgb = this.hexToRGB(hex);
    return `rgba(${rgb.r}, ${rgb.g}, ${rgb.b}, ${alpha})`;
  }

  private adjustColorTemp(temp: number): string {
    // 简化色温到RGB转换
    if (temp < 5000) return '#FFD6A5'; // 暖白
    if (temp > 7500) return '#C9D6FF'; // 冷白
    return '#FFFFFF'; // 中性白
  }
}

interface AlertConfig {
  baseColor: string;
  pulseColor: string;
  pulseFreq: number;
  intensity: number;
  borderFlash: boolean;
  hapticPattern: HapticType;
}

enum HapticType {
  NONE = 'none',
  LIGHT = 'light',
  MEDIUM = 'medium',
  HEAVY = 'heavy'
}

3.3 多智能体协同决策系统

基于HarmonyOS 6的MultiAgentFramework，我们构建三个协同工作的AI智能体：指挥决策智能体、灾情分析智能体、资源调度智能体。它们通过共享黑板（Blackboard）机制协同推理。

代码亮点：黑板机制通信、智能体角色分工、冲突消解策略、端侧推理保护敏感数据。

// MultiAgentSystem.ets
// 多智能体协同决策系统

import { MultiAgentFramework, AgentRole, Blackboard } from '@kit.MultiAgent';
import { MindSporeLite } from '@kit.MindSporeLite';
import { DistributedData } from '@kit.DistributedService';

export class EmergencyAgentSystem {
  private static instance: EmergencyAgentSystem;
  private framework: MultiAgentFramework;
  private blackboard: Blackboard;
  private agents: Map<string, BaseAgent> = new Map();

  // 智能体配置
  private readonly AGENT_CONFIGS: AgentConfig[] = [
    {
      id: 'command_agent',
      name: '指挥决策智能体',
      role: AgentRole.DECISION,
      modelPath: '/assets/models/command_llm.mindir',
      priority: 1  // 最高优先级
    },
    {
      id: 'analysis_agent',
      name: '灾情分析智能体',
      role: AgentRole.ANALYSIS,
      modelPath: '/assets/models/analysis_llm.mindir',
      priority: 2
    },
    {
      id: 'dispatch_agent',
      name: '资源调度智能体',
      role: AgentRole.EXECUTION,
      modelPath: '/assets/models/dispatch_llm.mindir',
      priority: 3
    }
  ];

  private constructor() {
    this.framework = new MultiAgentFramework({
      communicationMode: 'blackboard',  // 黑板共享机制
      conflictResolution: 'priority',   // 优先级冲突消解
      maxConcurrentAgents: 3,
      inferenceDevice: DeviceType.NPU
    });

    this.blackboard = this.framework.createBlackboard('emergency_bb');
    this.initializeAgents();
  }

  static getInstance(): EmergencyAgentSystem {
    if (!EmergencyAgentSystem.instance) {
      EmergencyAgentSystem.instance = new EmergencyAgentSystem();
    }
    return EmergencyAgentSystem.instance;
  }

  // 初始化所有智能体
  private async initializeAgents(): Promise<void> {
    for (const config of this.AGENT_CONFIGS) {
      const agent = await this.createAgent(config);
      this.agents.set(config.id, agent);
      this.framework.registerAgent(agent);
    }

    // 启动黑板监听
    this.startBlackboardMonitor();
  }

  // 创建单个智能体
  private async createAgent(config: AgentConfig): Promise<BaseAgent> {
    const model = await MindSporeLite.loadModel({
      modelPath: config.modelPath,
      deviceType: DeviceType.NPU,
      precisionMode: PrecisionMode.FP16
    });

    switch (config.role) {
      case AgentRole.DECISION:
        return new CommandAgent(config.id, config.name, model, this.blackboard);
      case AgentRole.ANALYSIS:
        return new AnalysisAgent(config.id, config.name, model, this.blackboard);
      case AgentRole.EXECUTION:
        return new DispatchAgent(config.id, config.name, model, this.blackboard);
      default:
        throw new Error(`未知智能体角色: ${config.role}`);
    }
  }

  // 启动黑板监控
  private startBlackboardMonitor(): void {
    this.blackboard.onUpdate((key: string, value: any) => {
      // 黑板数据变化时，路由给相关智能体
      this.routeBlackboardUpdate(key, value);
    });
  }

  // 路由黑板更新
  private routeBlackboardUpdate(key: string, value: any): void {
    switch (key) {
      case 'disaster_report':
        // 灾情报告更新 -> 触发分析智能体
        this.agents.get('analysis_agent')?.handleUpdate('disaster', value);
        break;
      case 'resource_status':
        // 资源状态更新 -> 触发调度智能体
        this.agents.get('dispatch_agent')?.handleUpdate('resource', value);
        break;
      case 'analysis_result':
        // 分析结果 -> 触发指挥智能体决策
        this.agents.get('command_agent')?.handleUpdate('analysis', value);
        break;
      case 'dispatch_plan':
        // 调度计划 -> 指挥智能体审批
        this.agents.get('command_agent')?.handleUpdate('dispatch', value);
        break;
    }
  }

  // 提交灾情报告，启动智能体协同流程
  public async submitDisasterReport(report: DisasterReport): Promise<<CommandDecision> {
    // 1. 写入黑板
    await this.blackboard.write('disaster_report', report);
    await this.blackboard.write('session_id', `session_${Date.now()}`);

    // 2. 等待分析智能体完成
    const analysisResult = await this.waitForAgent('analysis_agent', 'analysis_complete');

    // 3. 等待指挥智能体决策
    const decision = await this.waitForAgent('command_agent', 'decision_complete');

    // 4. 等待调度智能体生成方案
    const dispatchPlan = await this.waitForAgent('dispatch_agent', 'plan_complete');

    // 5. 整合结果返回
    return {
      decision: decision,
      analysis: analysisResult,
      dispatchPlan: dispatchPlan,
      confidence: this.calculateConfidence([analysisResult, decision, dispatchPlan])
    };
  }

  // 等待智能体完成指定任务
  private async waitForAgent(agentId: string, signal: string): Promise<any> {
    return new Promise((resolve) => {
      const checkInterval = setInterval(() => {
        const signalValue = this.blackboard.read(signal);
        if (signalValue) {
          clearInterval(checkInterval);
          resolve(signalValue);
        }
      }, 100);

      // 超时处理（30秒）
      setTimeout(() => {
        clearInterval(checkInterval);
        resolve({ error: 'timeout', agentId });
      }, 30000);
    });
  }

  // 计算综合置信度
  private calculateConfidence(results: any[]): number {
    const confidences = results.map(r => r.confidence || 0.5);
    return confidences.reduce((a, b) => a + b, 0) / confidences.length;
  }

  // 人工介入接口：覆盖智能体决策
  public async humanOverride(agentId: string, decision: any): Promise<void> {
    // 标记人工干预
    await this.blackboard.write('human_override', {
      agentId,
      decision,
      timestamp: Date.now()
    });

    // 暂停该智能体，等待人工确认
    this.agents.get(agentId)?.pause();
  }
}

// 指挥决策智能体
class CommandAgent extends BaseAgent {
  async handleUpdate(type: string, data: any): Promise<void> {
    switch (type) {
      case 'analysis':
        // 收到分析结果，生成指挥决策
        const decision = await this.generateDecision(data);
        await this.blackboard.write('command_decision', decision);
        await this.blackboard.write('decision_complete', true);
        break;
      case 'dispatch':
        // 审批调度计划
        const approved = await this.approveDispatchPlan(data);
        await this.blackboard.write('dispatch_approved', approved);
        break;
    }
  }

  private async generateDecision(analysis: any): Promise<any> {
    const prompt = `作为应急指挥专家，基于以下灾情分析生成指挥决策：
灾情等级：${analysis.level}
影响范围：${analysis.affectedArea}平方公里
人员伤亡：${analysis.casualties}
关键设施：${analysis.criticalFacilities.join(', ')}

请生成：
1. 响应等级建议
2. 首要处置目标
3. 资源调配优先级
4. 风险管控要点`;

    return await this.model.infer({ inputText: prompt, maxTokens: 512 });
  }

  private async approveDispatchPlan(plan: any): Promise<boolean> {
    // 检查计划合理性
    const checkPrompt = `审核调度计划：
${JSON.stringify(plan)}

判断是否符合安全规范与效率要求，回复"通过"或"驳回及原因"。`;

    const result = await this.model.infer({ inputText: checkPrompt, maxTokens: 128 });
    return result.includes('通过');
  }
}

// 灾情分析智能体
class AnalysisAgent extends BaseAgent {
  async handleUpdate(type: string, data: any): Promise<void> {
    if (type === 'disaster') {
      const analysis = await this.analyzeDisaster(data);
      await this.blackboard.write('analysis_result', analysis);
      await this.blackboard.write('analysis_complete', true);
    }
  }

  private async analyzeDisaster(report: DisasterReport): Promise<any> {
    // 多维度分析
    const [level, spread, impact] = await Promise.all([
      this.assessLevel(report),
      this.predictSpread(report),
      this.assessImpact(report)
    ]);

    return {
      level,
      spread,
      impact,
      confidence: (level.confidence + spread.confidence + impact.confidence) / 3,
      timestamp: Date.now()
    };
  }

  private async assessLevel(report: DisasterReport): Promise<any> {
    const prompt = `评估灾情等级：
类型：${report.type}
强度：${report.intensity}
持续时间：${report.duration}小时
已报告损失：${report.reportedDamage}

按国标GB/T 35561-2017评估等级（I-IV级），给出置信度。`;

    return await this.model.infer({ inputText: prompt, maxTokens: 256 });
  }

  private async predictSpread(report: DisasterReport): Promise<any> {
    // 结合气象、地理数据预测扩散
    const prompt = `预测灾情扩散：
当前位置：${report.location}
风向：${report.weather.windDirection} 风速：${report.weather.windSpeed}
地形：${report.terrain}
预测6小时、12小时、24小时影响范围。`;

    return await this.model.infer({ inputText: prompt, maxTokens: 256 });
  }

  private async assessImpact(report: DisasterReport): Promise<any> {
    const prompt = `评估社会影响：
人口密度：${report.populationDensity}/km²
关键设施：${report.nearbyFacilities.join(', ')}
交通状况：${report.trafficStatus}

评估对民生、经济、公共安全的潜在影响。`;

    return await this.model.infer({ inputText: prompt, maxTokens: 256 });
  }
}

// 资源调度智能体
class DispatchAgent extends BaseAgent {
  async handleUpdate(type: string, data: any): Promise<void> {
    if (type === 'resource') {
      const plan = await this.generateDispatchPlan(data);
      await this.blackboard.write('dispatch_plan', plan);
      await this.blackboard.write('plan_complete', true);
    }
  }

  private async generateDispatchPlan(resourceStatus: any): Promise<any> {
    const decision = this.blackboard.read('command_decision');

    const prompt = `生成资源调度方案：
可用资源：${JSON.stringify(resourceStatus.available)}
需求优先级：${JSON.stringify(decision.priorities)}
交通约束：${JSON.stringify(resourceStatus.routes)}

生成最优调度方案，要求：
1. 响应时间最短
2. 资源利用率最高
3. 留有安全冗余`;

    return await this.model.infer({ inputText: prompt, maxTokens: 512 });
  }
}

// 基类
abstract class BaseAgent {
  constructor(
    public id: string,
    public name: string,
    protected model: MindSporeLite.Model,
    protected blackboard: Blackboard
  ) {}

  abstract handleUpdate(type: string, data: any): Promise<void>;

  pause(): void {
    // 暂停智能体推理
    this.model.setActive(false);
  }

  resume(): void {
    this.model.setActive(true);
  }
}

interface AgentConfig {
  id: string;
  name: string;
  role: AgentRole;
  modelPath: string;
  priority: number;
}

interface DisasterReport {
  type: string;
  intensity: number;
  duration: number;
  location: string;
  affectedArea: number;
  casualties: number;
  criticalFacilities: string[];
  weather: { windDirection: string; windSpeed: number };
  terrain: string;
  populationDensity: number;
  nearbyFacilities: string[];
  trafficStatus: string;
  reportedDamage: string;
}

interface CommandDecision {
  decision: any;
  analysis: any;
  dispatchPlan: any;
  confidence: number;
}

3.4 主界面整合：AR应急指挥调度中心

将悬浮面板、预警光效与多智能体系统整合为完整的AR指挥应用。

// EmergencyCommandCenter.ets
// AR应急指挥调度中心主界面

import { ARScene, ARNode, ARPlane } from '@kit.ARKit';
import { EmergencyFloatPanels } from './EmergencyFloatPanels';
import { AlertLightSystem } from './AlertLightSystem';
import { EmergencyAgentSystem } from './MultiAgentSystem';
import { DistributedDeviceManager } from '@kit.DistributedService';

@Entry
@Component
struct EmergencyCommandCenter {
  @State isARReady: boolean = false;
  @State currentDisaster: DisasterReport | null = null;
  @State agentDecision: CommandDecision | null = null;
  @State dangerLevel: DangerLevel = DangerLevel.NORMAL;
  @State connectedDevices: string[] = [];
  @State isDistributedMode: boolean = false;

  private arScene: ARScene;
  private agentSystem: EmergencyAgentSystem;
  private alertSystem: AlertLightSystem;
  private deviceManager: DistributedDeviceManager;

  aboutToAppear() {
    // 初始化AR场景（支持水平和垂直平面）
    this.arScene = ARScene.create({
      planeDetection: [ARPlane.Type.HORIZONTAL, ARPlane.Type.VERTICAL],
      environmentTexturing: EnvironmentTexturing.AUTOMATIC,
      sceneReconstruction: true  // 启用场景重建
    });

    // 初始化子系统
    this.agentSystem = EmergencyAgentSystem.getInstance();
    this.alertSystem = AlertLightSystem.getInstance();

    // 初始化分布式设备管理
    this.initDistributedMode();

    // 加载应急资源3D模型
    this.loadEmergencyModels();
  }

  // 初始化分布式协同
  private async initDistributedMode(): Promise<void> {
    this.deviceManager = new DistributedDeviceManager();

    // 发现周边鸿蒙设备
    const devices = await this.deviceManager.discover({
      filter: { deviceType: ['phone', 'tablet', 'wearable', 'pc'] },
      timeout: 5000
    });

    this.connectedDevices = devices.map(d => d.name);

    // 尝试建立分布式会话
    if (devices.length > 0) {
      await this.deviceManager.createSession('emergency_cmd', {
        devices: devices,
        dataSync: true,
        priority: SessionPriority.HIGH
      });
      this.isDistributedMode = true;
    }
  }

  // 加载应急资源3D模型
  private async loadEmergencyModels(): Promise<void> {
    const models = [
      { id: 'fire_truck', name: '消防车', type: 'vehicle' },
      { id: 'ambulance', name: '救护车', type: 'vehicle' },
      { id: 'command_tent', name: '指挥帐篷', type: 'facility' },
      { id: 'drone', name: '侦察无人机', type: 'aircraft' }
    ];

    for (const model of models) {
      const node = await ARNode.loadModel(`assets/models/${model.id}.glb`);
      node.visible = false;
      node.userData = model;
      node.scale = { x: 0.5, y: 0.5, z: 0.5 }; // 初始缩放
      this.arScene.addNode(node);
    }
  }

  // 提交灾情并启动智能体分析
  private async submitDisaster(report: DisasterReport): Promise<void> {
    this.currentDisaster = report;

    // 显示加载状态
    this.showLoading('智能体协同分析中...');

    // 提交给多智能体系统
    const decision = await this.agentSystem.submitDisasterReport(report);
    this.agentDecision = decision;

    // 根据决策更新危险等级
    const newLevel = this.mapDecisionToDangerLevel(decision);
    this.updateDangerLevel(newLevel);

    // 在AR场景中部署资源模型
    this.deployResourcesInAR(decision.dispatchPlan);

    this.hideLoading();
  }

  // 更新危险等级
  private updateDangerLevel(level: DangerLevel): void {
    this.dangerLevel = level;
    this.alertSystem.setDangerLevel(level);

    // 同步到分布式设备
    if (this.isDistributedMode) {
      this.deviceManager.broadcast('danger_level', { level, timestamp: Date.now() });
    }
  }

  // 在AR场景中部署资源
  private async deployResourcesInAR(plan: any): Promise<void> {
    const deployments = plan.deployments || [];

    for (const deploy of deployments) {
      const node = this.arScene.getNode(deploy.resourceType);
      if (node) {
        // 将屏幕坐标转换为AR世界坐标
        const worldPos = ARScene.gpsToWorld(deploy.gpsLocation);
        node.position = worldPos;
        node.visible = true;

        // 添加部署动画
        await this.animateDeployment(node);

        // 添加信息标签
        this.addResourceLabel(node, deploy);
      }
    }
  }

  // 资源部署动画
  private async animateDeployment(node: ARNode): Promise<void> {
    // 从天空降落到地面
    const startY = node.position.y + 5;
    const endY = node.position.y;

    node.position.y = startY;
    node.opacity = 0;

    // 下落动画
    const animation = node.animate({
      duration: 1500,
      easing: EasingType.EASE_OUT_BOUNCE
    });

    animation.addKeyframe(0, { y: startY, opacity: 0 });
    animation.addKeyframe(0.6, { y: endY + 0.5, opacity: 1 });
    animation.addKeyframe(1.0, { y: endY, opacity: 1 });

    await animation.start();
  }

  // 添加资源信息标签
  private addResourceLabel(node: ARNode, deploy: any): void {
    const labelNode = ARNode.createLabel({
      text: `${deploy.resourceName}\n状态: ${deploy.status}\n预计到达: ${deploy.eta}分钟`,
      fontSize: 14,
      backgroundColor: 'rgba(0,0,0,0.7)',
      textColor: '#FFFFFF',
      padding: 8
    });

    labelNode.position = {
      x: node.position.x,
      y: node.position.y + 1.2, // 资源上方1.2米
      z: node.position.z
    };

    labelNode.billboardMode = BillboardMode.BILLBOARD_Y;
    this.arScene.addNode(labelNode);
  }

  build() {
    Stack() {
      // AR场景层
      ARSceneView({
        scene: this.arScene,
        onPlaneDetected: (plane: ARPlane) => {
          this.isARReady = true;
          // 在检测到的平面上显示操作提示
          this.showPlaneHint(plane);
        },
        onNodeTapped: (node: ARNode) => {
          this.handleResourceTap(node);
        },
        onLongPress: (point: Position) => {
          // 长按标记新灾情点
          this.markDisasterPoint(point);
        }
      })
      .width('100%')
      .height('100%');

      // 沉浸预警光效系统
      AlertLightSystem();

      // 悬浮指挥面板（AR就绪后显示）
      if (this.isARReady) {
        EmergencyFloatPanels({
          onDangerLevelChange: (level: DangerLevel) => {
            this.updateDangerLevel(level);
          }
        });
      }

      // 灾情快速录入面板（左侧滑出）
      if (this.isARReady && !this.currentDisaster) {
        DisasterInputPanel({
          onSubmit: (report: DisasterReport) => this.submitDisaster(report)
        })
        .align(Alignment.Start)
        .margin({ left: 20, top: 100 });
      }

      // 智能体决策展示面板
      if (this.agentDecision) {
        AgentDecisionCard({
          decision: this.agentDecision,
          onApprove: () => this.executeDecision(this.agentDecision),
          onModify: () => this.showDecisionEditor()
        })
        .align(Alignment.Center)
        .backgroundColor('rgba(28,28,30,0.95)')
        .borderRadius(16)
        .padding(20);
      }

      // 分布式设备状态栏
      if (this.isDistributedMode) {
        DistributedDeviceBar({
          devices: this.connectedDevices,
          onDeviceSelect: (device: string) => this.focusDevice(device)
        })
        .align(Alignment.TopEnd)
        .margin({ top: 20, right: 20 });
      }

      // 底部操作栏
      CommandBottomBar({
        onScanDisaster: () => this.startDisasterScan(),
        onVoiceCommand: () => this.startVoiceCommand(),
        onResourceView: () => this.toggleResourceView(),
        onDistributedToggle: () => this.toggleDistributedMode()
      })
      .align(Alignment.Bottom)
      .margin({ bottom: 30 });
    }
    .width('100%')
    .height('100%')
    .backgroundColor('#000000');
  }

  // 处理资源节点点击
  private async handleResourceTap(node: ARNode): Promise<void> {
    if (node.userData?.type === 'vehicle') {
      // 显示资源详情与调度选项
      const detail = await this.agentSystem.queryResourceDetail(node.userData.id);
      this.showResourceDetailModal(detail);
    }
  }

  // 标记灾情点
  private async markDisasterPoint(point: Position): Promise<void> {
    const worldPos = ARScene.screenToWorld(point);

    // 创建灾情标记
    const marker = ARNode.createMarker({
      shape: MarkerShape.PIN,
      color: '#FF3B30',
      size: 0.3,
      pulse: true
    });

    marker.position = worldPos;
    this.arScene.addNode(marker);

    // 自动填充灾情位置
    this.prefillDisasterLocation(worldPos);
  }

  // 启动语音指挥
  private async startVoiceCommand(): Promise<void> {
    const audioData = await this.recordVoice();

    // 语音转指令
    const command = await this.agentSystem.parseVoiceCommand(audioData);

    // 执行指令
    switch (command.type) {
      case 'deploy':
        await this.deployResourcesInAR(command.plan);
        break;
      case 'alert':
        this.updateDangerLevel(command.level);
        break;
      case 'query':
        const info = await this.agentSystem.queryStatus(command.target);
        this.showQueryResult(info);
        break;
    }
  }

  // 其他辅助方法...
  private showPlaneHint(plane: ARPlane): void {
    // 在检测到的平面上显示半透明提示
  }

  private prefillDisasterLocation(pos: Vector3): void {
    // 将AR坐标转换为GPS坐标并预填充表单
  }

  private mapDecisionToDangerLevel(decision: CommandDecision): DangerLevel {
    const level = decision.decision?.responseLevel || 'IV';
    const map: Record<string, DangerLevel> = {
      'I': DangerLevel.CRITICAL,
      'II': DangerLevel.WARNING,
      'III': DangerLevel.CAUTION,
      'IV': DangerLevel.NORMAL
    };
    return map[level] || DangerLevel.NORMAL;
  }

  private showLoading(msg: string): void { /* ... */ }
  private hideLoading(): void { /* ... */ }
  private showResourceDetailModal(detail: any): void { /* ... */ }
  private showDecisionEditor(): void { /* ... */ }
  private focusDevice(device: string): void { /* ... */ }
  private startDisasterScan(): void { /* ... */ }
  private toggleResourceView(): void { /* ... */ }
  private toggleDistributedMode(): void { /* ... */ }
  private executeDecision(decision: CommandDecision): void { /* ... */ }
  private showQueryResult(info: any): void { /* ... */ }
}

---

四、关键特性深度解析

4.1 多面板智能避让机制

HarmonyOS 6的PanelGroup在应急场景中实现了多面板动态平衡：

1. 碰撞检测：每50ms检测面板重叠，自动触发分离算法
2. 优先级吸附：高优先级面板（如态势面板）在碰撞时保持位置，低优先级面板自动避让
3. 边缘智能：面板靠近屏幕边缘时自动吸附，留出中央视野区
4. 危险响应：当危险等级提升至CRITICAL时，所有面板自动收缩至屏幕四角，最大化现场视野

4.2 光效-危险映射的生理友好设计

传统警示系统的高频闪烁可能引发光敏性癫痫。我们的设计遵循生理节律友好原则：

• 频率限制：最高闪烁频率限制在2Hz（120次/分钟），低于危险阈值
• 色温保护：避免纯蓝光（<<450nm）高频闪烁，采用暖色系警示
• 渐进过渡：危险等级变化时，光效渐变过渡3秒，避免突变刺激
• 触觉协同：高危险等级时同步触发触觉反馈，降低对视觉的单一依赖

4.3 多智能体黑板机制

三个智能体通过共享黑板协同工作，避免传统消息传递的耦合问题：

• 黑板结构：disaster_report（输入）、analysis_result（分析）、command_decision（决策）、dispatch_plan（调度）
• 触发机制：数据写入黑板后，自动触发订阅该键的智能体
• 冲突消解：当指挥智能体与调度智能体意见冲突时，按优先级（指挥>分析>调度）裁决
• 人工覆盖：指挥员可随时写入human_override键，暂停智能体并接管决策

---

五、应用场景与生态价值

5.1 城市消防指挥

消防员佩戴AR眼镜进入火场，指挥员在指挥中心通过平板查看现场AR态势。悬浮面板显示建筑结构、人员位置、火势蔓延预测，智能体实时推荐最优救援路线。

5.2 自然灾害应急

地震/洪水场景下，多部门（消防、医疗、民政）通过分布式协同进入同一AR指挥空间。各终端的悬浮面板数据实时同步，智能体统筹资源避免重复调度。

5.3 大型活动安保

演唱会、体育赛事等场景，安保人员通过AR眼镜识别可疑人员与物品。危险等级光效系统让安保负责人无需注视屏幕即可感知全局安全态势。

---

六、总结与展望

本文完整展示了基于HarmonyOS 6（API 23）开发AR应急指挥调度中心的技术路径。通过悬浮导航实现AR场景的多面板协同与智能避让，通过沉浸光感达成物理空间的危险感知同步，通过多智能体系统实现指挥决策的智能化与协同化。

随着HarmonyOS生态的持续演进，我们期待看到：

1. 数字孪生融合：将真实城市数据实时映射到AR空间，实现虚实完全同步
2. 脑机接口预警：通过可穿戴设备监测指挥员生理状态，在疲劳/高压时自动降低信息密度
3. 自主无人机协同：智能体直接控制无人机群执行侦察与物资投送，人类指挥员专注决策

城市安全关乎千家万户，HarmonyOS 6正为应急管理提供前所未有的技术能力。期待更多开发者加入鸿蒙生态，共同探索AR+AI在城市治理领域的创新应用。

---

转载自：https://blog.csdn.net/u014727709/article/details/161483342
欢迎 👍点赞✍评论⭐收藏，欢迎指正
