HARMONYOS应用实例264：数据统计图表生成器
·
模块四：统计与概率 (31-37)
- 数据统计图表生成器
- 功能：输入班级成绩数据，一键生成条形图、折线图、扇形图，并自动计算平均数、中位数。
输入班级成绩数据（姓名和成绩）
一键生成三种类型的统计图表：条形图、折线图、扇形图
自动计算并显示统计结果：平均数、中位数、最高分、最低分、人数
支持添加、删除和清空成绩数据
提供显示选项控制（网格、标签）
可视化展示成绩分布情况
- 功能：输入班级成绩数据，一键生成条形图、折线图、扇形图，并自动计算平均数、中位数。
// 数据统计图表生成器
// 功能：输入班级成绩数据，一键生成条形图、折线图、扇形图，并自动计算平均数、中位数
// 成绩数据接口
interface ScoreData {
id: number;
name: string;
score: number;
}
// 统计结果接口
interface StatisticsResult {
average: number;
median: number;
max: number;
min: number;
count: number;
}
// 分数段数据接口
interface ScoreRange {
range: string;
count: number;
color: string;
}
@Entry
@Component
struct StatisticsChartGenerator {
@State canvasWidth: number = 350;
@State canvasHeight: number = 350;
@State chartType: 'bar' | 'line' | 'pie' = 'bar';
@State showGrid: boolean = true;
@State showLabels: boolean = true;
@State scoreData: ScoreData[] = [];
@State statistics: StatisticsResult = {
average: 0,
median: 0,
max: 0,
min: 0,
count: 0
};
@State inputName: string = '';
@State inputScore: string = '';
@State editingId: number | null = null;
build() {
Column({ space: 15 }) {
Text('数据统计图表生成器')
.fontSize(26)
.fontWeight(FontWeight.Bold)
.textAlign(TextAlign.Center)
Column() {
Text('功能介绍')
.fontSize(18)
.fontWeight(FontWeight.Medium)
Text('输入班级成绩数据，一键生成条形图、折线图、扇形图，并自动计算平均数、中位数，帮助教师快速分析学生成绩分布情况')
.fontSize(14)
.fontColor('#666666')
.textAlign(TextAlign.Center)
}
.width('100%')
.backgroundColor('#E3F2FD')
.borderRadius(10)
.padding(15)
Column({ space: 10 }) {
Text('数据输入')
.fontSize(18)
.fontWeight(FontWeight.Bold)
.width('100%')
.textAlign(TextAlign.Center)
Column({ space: 8 }) {
Text('姓名')
.fontSize(14)
.fontColor('#666666')
TextInput({ placeholder: '请输入姓名' })
.width('100%')
.height(40)
.fontSize(14)
.onChange((value: string) => {
this.inputName = value
})
}
.width('100%')
.padding(8)
.backgroundColor('#F5F5F5')
.borderRadius(6)
Column({ space: 8 }) {
Text('成绩')
.fontSize(14)
.fontColor('#666666')
TextInput({ placeholder: '请输入成绩(0-100)' })
.width('100%')
.height(40)
.fontSize(14)
.type(InputType.Number)
.onChange((value: string) => {
this.inputScore = value
})
}
.width('100%')
.padding(8)
.backgroundColor('#F5F5F5')
.borderRadius(6)
Row({ space: 10 }) {
Button('添加数据')
.width('48%')
.height(40)
.fontSize(14)
.backgroundColor('#4CAF50')
.onClick(() => {
this.addData()
})
Button('清空数据')
.width('48%')
.height(40)
.fontSize(14)
.backgroundColor('#F44336')
.onClick(() => {
this.clearData()
})
}
.width('100%')
.justifyContent(FlexAlign.SpaceBetween)
}
.width('90%')
.padding(10)
.backgroundColor('#FAFAFA')
.borderRadius(10)
Column({ space: 10 }) {
Text('成绩列表')
.fontSize(18)
.fontWeight(FontWeight.Bold)
.width('100%')
.textAlign(TextAlign.Center)
if (this.scoreData.length > 0) {
Column({ space: 5 }) {
ForEach(this.scoreData, (data: ScoreData, index: number) => {
Row({ space: 10 }) {
Text(`${index + 1}. ${data.name}`)
.fontSize(14)
.width('40%')
Text(`${data.score}分`)
.fontSize(14)
.fontColor('#2196F3')
.width('30%')
Button('删除')
.width('25%')
.height(30)
.fontSize(12)
.backgroundColor('#F44336')
.onClick(() => {
this.deleteData(index)
})
}
.width('100%')
.padding(8)
.backgroundColor('#FFFFFF')
.borderRadius(6)
.border({ width: 1, color: '#E0E0E0' })
})
}
.width('100%')
.padding(10)
.backgroundColor('#F5F5F5')
.borderRadius(8)
} else {
Column() {
Text('暂无数据')
.fontSize(14)
.fontColor('#999999')
}
.width('100%')
.padding(20)
.backgroundColor('#F5F5F5')
.borderRadius(8)
}
}
.width('100%')
.padding(10)
.backgroundColor('#FAFAFA')
.borderRadius(10)
Column({ space: 10 }) {
Text('统计结果')
.fontSize(18)
.fontWeight(FontWeight.Bold)
.width('100%')
.textAlign(TextAlign.Center)
if (this.scoreData.length > 0) {
Column({ space: 8 }) {
Row({ space: 10 }) {
Text(`平均数: ${this.statistics.average.toFixed(2)}`)
.fontSize(14)
.fontColor('#2196F3')
Text(`中位数: ${this.statistics.median.toFixed(2)}`)
.fontSize(14)
.fontColor('#4CAF50')
}
.width('100%')
.justifyContent(FlexAlign.SpaceAround)
Row({ space: 10 }) {
Text(`最高分: ${this.statistics.max}`)
.fontSize(14)
.fontColor('#FF9800')
Text(`最低分: ${this.statistics.min}`)
.fontSize(14)
.fontColor('#F44336')
Text(`人数: ${this.statistics.count}`)
.fontSize(14)
.fontColor('#9C27B0')
}
.width('100%')
.justifyContent(FlexAlign.SpaceAround)
}
.width('100%')
.padding(15)
.backgroundColor('#E8F5E9')
.borderRadius(10)
} else {
Column() {
Text('请先输入成绩数据')
.fontSize(14)
.fontColor('#999999')
}
.width('100%')
.padding(15)
.backgroundColor('#F5F5F5')
.borderRadius(10)
}
}
.width('100%')
.padding(10)
.backgroundColor('#FAFAFA')
.borderRadius(10)
Column({ space: 10 }) {
Text('图表类型')
.fontSize(18)
.fontWeight(FontWeight.Bold)
.width('100%')
.textAlign(TextAlign.Center)
Row({ space: 10 }) {
Button('条形图')
.width('31%')
.height(40)
.fontSize(14)
.backgroundColor(this.chartType === 'bar' ? '#2196F3' : '#E0E0E0')
.onClick(() => {
this.chartType = 'bar'
this.drawChart()
})
Button('折线图')
.width('31%')
.height(40)
.fontSize(14)
.backgroundColor(this.chartType === 'line' ? '#2196F3' : '#E0E0E0')
.onClick(() => {
this.chartType = 'line'
this.drawChart()
})
Button('扇形图')
.width('31%')
.height(40)
.fontSize(14)
.backgroundColor(this.chartType === 'pie' ? '#2196F3' : '#E0E0E0')
.onClick(() => {
this.chartType = 'pie'
this.drawChart()
})
}
.width('100%')
.justifyContent(FlexAlign.SpaceBetween)
}
.width('90%')
.padding(10)
.backgroundColor('#FAFAFA')
.borderRadius(10)
Column({ space: 10 }) {
Text('统计图表')
.fontSize(18)
.fontWeight(FontWeight.Bold)
.width('100%')
.textAlign(TextAlign.Center)
Canvas(this.canvasContext)
.width(this.canvasWidth)
.height(this.canvasHeight)
.backgroundColor('#FFFFFF')
.border({ width: 2, color: '#333' })
.borderRadius(10)
.onReady(() => {
this.drawChart()
})
}
.width('100%')
.padding(10)
.backgroundColor('#FAFAFA')
.borderRadius(10)
Column({ space: 8 }) {
Text('显示选项')
.fontSize(16)
.fontWeight(FontWeight.Medium)
Row({ space: 10 }) {
Row({ space: 5 }) {
Text('显示网格')
.fontSize(14)
Text(this.showGrid ? '✓' : '✗')
.fontSize(14)
.fontColor(this.showGrid ? '#4CAF50' : '#F44336')
}
.onClick(() => {
this.showGrid = !this.showGrid
this.drawChart()
})
Row({ space: 5 }) {
Text('显示标签')
.fontSize(14)
Text(this.showLabels ? '✓' : '✗')
.fontSize(14)
.fontColor(this.showLabels ? '#4CAF50' : '#F44336')
}
.onClick(() => {
this.showLabels = !this.showLabels
this.drawChart()
})
}
.width('100%')
.justifyContent(FlexAlign.SpaceAround)
}
.width('90%')
.padding(10)
.backgroundColor('#F5F5F5')
.borderRadius(8)
Column({ space: 8 }) {
Text('使用说明')
.fontSize(16)
.fontWeight(FontWeight.Bold)
Text('• 输入学生姓名和成绩')
.fontSize(14)
.fontColor('#666666')
Text('• 点击"添加数据"保存成绩')
.fontSize(14)
.fontColor('#666666')
Text('• 选择图表类型查看统计')
.fontSize(14)
.fontColor('#666666')
Text('• 查看平均数、中位数等统计结果')
.fontSize(14)
.fontColor('#666666')
Text('• 使用"清空数据"重新开始')
.fontSize(14)
.fontColor('#666666')
}
.width('95%')
.padding(12)
.backgroundColor('#FFF3E0')
.borderRadius(10)
}
.width('100%')
.height('100%')
.padding(10)
.justifyContent(FlexAlign.Start)
}
private canvasContext: CanvasRenderingContext2D = new CanvasRenderingContext2D();
private addData() {
if (this.inputName.trim() === '' || this.inputScore.trim() === '') {
return
}
const score = parseFloat(this.inputScore)
if (isNaN(score) || score < 0 || score > 100) {
return
}
const newData: ScoreData = {
id: Date.now(),
name: this.inputName,
score: score
}
this.scoreData.push(newData)
this.inputName = ''
this.inputScore = ''
this.calculateStatistics()
this.drawChart()
}
private deleteData(index: number) {
this.scoreData.splice(index, 1)
this.calculateStatistics()
this.drawChart()
}
private clearData() {
this.scoreData = []
this.inputName = ''
this.inputScore = ''
this.calculateStatistics()
this.drawChart()
}
private calculateStatistics() {
if (this.scoreData.length === 0) {
this.statistics = {
average: 0,
median: 0,
max: 0,
min: 0,
count: 0
}
return
}
const scores = this.scoreData.map((data: ScoreData) => data.score)
const sum = scores.reduce((acc: number, val: number) => acc + val, 0)
const average = sum / scores.length
const sortedScores = [...scores].sort((a: number, b: number) => a - b)
const median = sortedScores.length % 2 === 0
? (sortedScores[sortedScores.length / 2 - 1] + sortedScores[sortedScores.length / 2]) / 2
: sortedScores[Math.floor(sortedScores.length / 2)]
const max = Math.max(...scores)
const min = Math.min(...scores)
const count = scores.length
this.statistics = {
average,
median,
max,
min,
count
}
}
private drawChart() {
const ctx = this.canvasContext
ctx.clearRect(0, 0, this.canvasWidth, this.canvasHeight)
if (this.scoreData.length === 0) {
ctx.fillStyle = '#999999'
ctx.font = '16px sans-serif'
ctx.fillText('请先添加成绩数据', this.canvasWidth / 2 - 80, this.canvasHeight / 2)
return
}
switch (this.chartType) {
case 'bar':
this.drawBarChart(ctx)
break
case 'line':
this.drawLineChart(ctx)
break
case 'pie':
this.drawPieChart(ctx)
break
}
}
private drawBarChart(ctx: CanvasRenderingContext2D) {
const padding = 60
const chartWidth = this.canvasWidth - 2 * padding
const chartHeight = this.canvasHeight - 2 * padding
const barWidth = chartWidth / this.scoreData.length - 10
const maxScore = 100
if (this.showGrid) {
this.drawGrid(ctx, padding, chartWidth, chartHeight)
}
this.drawAxes(ctx, padding, chartWidth, chartHeight)
const colors = ['#2196F3', '#4CAF50', '#FF9800', '#9C27B0', '#F44336', '#00BCD4', '#8BC34A', '#FF5722']
this.scoreData.forEach((data: ScoreData, index: number) => {
const barHeight = (data.score / maxScore) * chartHeight
const x = padding + index * (barWidth + 10) + 5
const y = padding + chartHeight - barHeight
ctx.fillStyle = colors[index % colors.length]
ctx.fillRect(x, y, barWidth, barHeight)
if (this.showLabels) {
ctx.fillStyle = '#333'
ctx.font = '10px sans-serif'
ctx.fillText(data.score.toString(), x + barWidth / 2 - 10, y - 5)
ctx.font = '8px sans-serif'
ctx.fillText(data.name.substring(0, 3), x + barWidth / 2 - 10, padding + chartHeight + 15)
}
})
}
private drawLineChart(ctx: CanvasRenderingContext2D) {
const padding = 60
const chartWidth = this.canvasWidth - 2 * padding
const chartHeight = this.canvasHeight - 2 * padding
const maxScore = 100
if (this.showGrid) {
this.drawGrid(ctx, padding, chartWidth, chartHeight)
}
this.drawAxes(ctx, padding, chartWidth, chartHeight)
const pointSpacing = chartWidth / (this.scoreData.length - 1 || 1)
ctx.strokeStyle = '#2196F3'
ctx.lineWidth = 2
ctx.beginPath()
this.scoreData.forEach((data: ScoreData, index: number) => {
const x = padding + index * pointSpacing
const y = padding + chartHeight - (data.score / maxScore) * chartHeight
if (index === 0) {
ctx.moveTo(x, y)
} else {
ctx.lineTo(x, y)
}
})
ctx.stroke()
this.scoreData.forEach((data: ScoreData, index: number) => {
const x = padding + index * pointSpacing
const y = padding + chartHeight - (data.score / maxScore) * chartHeight
ctx.fillStyle = '#2196F3'
ctx.beginPath()
ctx.arc(x, y, 5, 0, 2 * Math.PI)
ctx.fill()
if (this.showLabels) {
ctx.fillStyle = '#333'
ctx.font = '10px sans-serif'
ctx.fillText(data.score.toString(), x - 10, y - 10)
ctx.font = '8px sans-serif'
ctx.fillText(data.name.substring(0, 3), x - 10, padding + chartHeight + 15)
}
})
}
private drawPieChart(ctx: CanvasRenderingContext2D) {
const centerX = this.canvasWidth / 2
const centerY = this.canvasHeight / 2
const radius = Math.min(centerX, centerY) - 40
const scoreRanges: ScoreRange[] = [
{ range: '90-100', count: 0, color: '#4CAF50' },
{ range: '80-89', count: 0, color: '#2196F3' },
{ range: '70-79', count: 0, color: '#FF9800' },
{ range: '60-69', count: 0, color: '#9C27B0' },
{ range: '0-59', count: 0, color: '#F44336' }
]
this.scoreData.forEach((data: ScoreData) => {
if (data.score >= 90) {
scoreRanges[0].count++
} else if (data.score >= 80) {
scoreRanges[1].count++
} else if (data.score >= 70) {
scoreRanges[2].count++
} else if (data.score >= 60) {
scoreRanges[3].count++
} else {
scoreRanges[4].count++
}
})
let startAngle = -Math.PI / 2
scoreRanges.forEach((range: ScoreRange) => {
if (range.count > 0) {
const sliceAngle = (range.count / this.scoreData.length) * 2 * Math.PI
ctx.fillStyle = range.color
ctx.beginPath()
ctx.moveTo(centerX, centerY)
ctx.arc(centerX, centerY, radius, startAngle, startAngle + sliceAngle)
ctx.closePath()
ctx.fill()
if (this.showLabels) {
const labelAngle = startAngle + sliceAngle / 2
const labelX = centerX + (radius * 0.7) * Math.cos(labelAngle)
const labelY = centerY + (radius * 0.7) * Math.sin(labelAngle)
ctx.fillStyle = '#FFFFFF'
ctx.font = '12px sans-serif'
ctx.fillText(`${range.range}: ${range.count}人`, labelX - 30, labelY)
}
startAngle += sliceAngle
}
})
}
private drawGrid(ctx: CanvasRenderingContext2D, padding: number, chartWidth: number, chartHeight: number) {
ctx.strokeStyle = '#E0E0E0'
ctx.lineWidth = 1
for (let i = 0; i <= 10; i++) {
const y = padding + (chartHeight / 10) * i
ctx.beginPath()
ctx.moveTo(padding, y)
ctx.lineTo(padding + chartWidth, y)
ctx.stroke()
}
}
private drawAxes(ctx: CanvasRenderingContext2D, padding: number, chartWidth: number, chartHeight: number) {
ctx.strokeStyle = '#333'
ctx.lineWidth = 2
ctx.beginPath()
ctx.moveTo(padding, padding)
ctx.lineTo(padding, padding + chartHeight)
ctx.lineTo(padding + chartWidth, padding + chartHeight)
ctx.stroke()
ctx.fillStyle = '#333'
ctx.font = '12px sans-serif'
ctx.fillText('成绩', padding - 20, padding - 10)
ctx.fillText('学生', padding + chartWidth - 20, padding + chartHeight + 20)
for (let i = 0; i <= 10; i++) {
const y = padding + (chartHeight / 10) * i
ctx.fillText((100 - i * 10).toString(), padding - 25, y + 4)
}
}
}
讨论HarmonyOS开发技术，专注于API与组件、DevEco Studio、测试、元服务和应用上架分发等。
更多推荐
0
0- 0
已为社区贡献400条内容
所有评论(0)
